Page 1: User Manual
RC160MHXEA Air to Water Heat Pump -Mono Control Unit user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register DB98-00000A(1) PDF processed with CutePDF evaluation edition www.CutePDF.com RC120MHXGA_IB_E_00000A(1).indd 53... -
Page 2: Important Safety Symbols And Precautions
Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual. If you have any questions, call your nearest contact center or find help and information online at www.samsung.com. Important safety symbols and precautions: WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 3 WARNING FOR POWER SUPPLY Remove all foreign substances such as dust or water from the power plug terminals and contact points using a dry cloth on a regular basis. • Unplug the power plug and clean it with a dry cloth. •...
-
Page 4: Safety Information
Safety information WARNING FOR USING Do not place an object near the outdoor unit that allows children to climb onto the machine. • This may result in children seriously injuring themselves. Do not use this air conditioner for long periods of time in badly ventilated locations or near infirm people. •... -
Page 5: Status Indicator
STATUS INDICATOR Mode Status Display Function Status Compressor On This icon indicates that the compressor in the outdoor unit is running. Back-up heater This icons indicate that the backup heater of the unit is operating, when there is a high demand for heating capacity. -
Page 6: Domestic Water Heating Operation
DOMESTIC WATER HEATING OPERATION In this mode, domestic water heating will be activated as required by the water temperature set point. • The set point can be set manually. 1. Press Power(DHW mode) button to turn on DHW tank. The priority between heating/cooling/water-law and DHW modes are depending upon the user’s input of Field Setting Value of Wired Remote Controller. -
Page 7: Outing Mode
OUTING MODE If you want to take a vacation, you can use the Outing hot key. When this mode is enabled, it is assured that the heat pump maintains your house at a lower temperature to save energy cost. 1. Press Outing Hot key. The heat pump delivers heat at a low temperature. -
Page 8: Operating Advanced Function
Operating advanced function SETTING THE TIME Your hydro unit contains a clock used to start and stop the unit automatically at a given time. You must set the time when you purchase the hydro unit or reset the main power. 1. Push the Set button for 3 seconds. -
Page 9: Setting The Daily Schedule
Operating advanced function SETTING THE DAILY SCHEDULE Set the daily schedule to reserve On / Off timer of DHW(Eco/Std/Power) and Silent mode. At most 15 schedules may be set for day. • If the field setting is for no use DHW and use other manufacturer tank, it is impossible to reserve “DHW”... - Page 10 4. Set the hour by pressing the Up or Down button. The ‘hour’ indicator will blink. Set the hour and press Set button to save the setting. 5. Set the minute by pressing the Up or Down button. The ‘minute’ indicator will blink. Set the minute and press Set button to save the setting.
- Page 11 Operating advanced function SETTING THE DAILY SCHEDULE Deleting the daily schedule 1. Select the schedule from Reservation View Mode. 2. Push the Cancel/Delete button for 3 seconds. 3. The LCD pictures change to the reservation mode after deleting the schedule. Operating the daily schedule 1. Operate automatically according to schedule.
- Page 12 RC120MHXGA_IB_E_00000A(1).indd 52 2011-10-13 오후 3:42:21...
