9. Make sure that the tape-drive power cable is connected to the tape-drive
power connector, J100 (see "System-board internal cable connectors" on page
11 for the location of the power connector).
10. Replace the hard disk drive backplane signal cable; make sure that it is
positioned on top of the SCSI signal cable and that both cables pass through
the cable clamp. Close the cable clamp.
11. Reconnect the hard disk drive backplane signal cable to the connector (J92)
on the system board (see "System-board internal cable connectors" on page 11
for the location of the hard disk drive backplane signal connector).
12. Reinstall the DIMM air baffle. Make sure that it clicks into place. You might
have to apply extra downward pressure to make sure that it is securely in
place.
13. Make sure that the SCSI signal cable is connected to the connector on the
SCSI adapter in slot 1 of the riser-card assembly.
14. Install the riser-card assembly. Arrange the excess length of the SCSI signal
cable to avoid blocking airflow to the heat sink in the area.
