MergePoint® SP Manager Installer/User Guide
72
To recover provisioning for an SP:
1. In the side navigation bar, click an SP name.
2. Click the Configuration tab.
3. In the top navigation bar, click Recover. The Provisioning Recover window appears.
4. Click Provisioning Recover.
NOTE: The Provisioning Recover button is only available after the provisioning on this SP is performed successfully
and confirmed.

Changing LAN parameters

To change LAN parameters:
1. In the side navigation bar, click an SP name.
2. Click the Configuration tab.
3. In the top navigation bar, click LAN. The LAN window appears.
4. From the IP Address Source drop-down menu, select Static or DHCP as the source type. If
you select Static as the source type, specify the SP's IP address, subnet mask and gateway
IP address in the fields provided.
NOTE: If you select DHCP, the SP's IP address is dynamically distributed from a DHCP server and the fields for
configuring a static IP cannot be edited.
5. Click Apply.

Host table

The host table is a simple text file that allows Admin user to associate IP addresses with
hostnames and alias.
To change the host name of the MergePoint SP manager:
1. Select Network - Host Table.
2. Enter a host name for the MergePoint SP manager in the Name field.
3. Click Apply.
To add an entry:
1. Select Network - Host Table, then click Add.
2. Enter the required information in the fields provided, then click Apply.
