Summary of Contents for ATEN CS-102U
- Page 1 USB KVM Switch USER MANUAL CS-102U...
-
Page 2: Fcc Information
FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. -
Page 3: Package Contents
Copyright © 2006 ATEN International Co., Ltd. Manual Part No. PAPE-XXXX-XXXX Manual Date: 2008-06-06 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 3 -... - Page 4 USB ports for peripheral devices that the connected computers can share. As a KVM switch, the CS-102U allows access to two computer systems from a single console (keyboard, mouse, and monitor) utilizing the USB connection for the console's keyboard and mouse.
- Page 5 Features Dual Function KVM / USB Switch - Two Switches In One Controls 2 Computers From a Single Console Over a USB Connection Using Standard USB Cables Simultaneous Reverse Operation - 2 Computers Can Share 2 USB Peripheral Devices Eliminates Driver Conflict Between the Console's Mouse and the Computers' Configuration Notebooks Can Use the Console's Mouse and Keyboard At the Same Time...
-
Page 6: System Requirements
System Requirements Console The console must consist of the following components: A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using on any computer in the installation. A USB keyboard A USB mouse Computers The following equipment must be installed on each computer that is to be connected to the system: Windows 98 / Mac OS 8.6 or higher... -
Page 7: Front View
Components Front View 1. Port Selection / Auto Scan Switch: This pushbutton has two functions: It toggles access back and forth between the computers. It activates / deactivates Auto Scan Mode. Holding this switch down for 2 seconds activates Auto Scan Mode; pressing and releasing the switch while Auto Scan Mode is active turns Auto Scan Mode Off. -
Page 8: Rear View
Rear View 1. Console Video Connector: The monitor's video cable plugs in here. 2. CPU Video Ports: These ports link to the video ports on the computers you are installing. 3. USB Peripheral Ports: USB peripherals that you want to use on the installation plug in here. -
Page 9: Installation
Video Port. 4. Plug the USB B end of the second KVM cable supplied with this package into the CS-102U's CPU 2 USB Port; plug the cable's video connector into the CPU 2 Video Port. 5. Plug the USB A end of the KVM cable into the second computer's USB Port;... - Page 10 In PNP AND PCI SETUP, set PNP OS INSTALLED to: YES; set USB IRQ to: ENABLED. 2. The CS-102U's Power On default is to link to Port 1. If the computer attached to Port 1 is inactive, the monitor will be blank so it may appear as if the unit is not functioning.
-
Page 11: Operation
Manual Port Selection With Manual Port Selection you simply press the Port Selection Button on the CS-102U's top panel to switch the KVM focus back and forth between computers. The Port LEDs light to indicate which port has the focus. -
Page 12: Auto Scan Mode
Therefore, if you have peripheral devices (other than a second keyboard and mouse) connected to the CS-102U's USB peripheral ports, you must be sure that the USB drivers for them are shut down on both comuters before invoking Auto Scan Mode. -
Page 13: Troubleshooting
Unplug the keyboard from the Console to be reset. Keyboard Port, then plug it/them back in. CS-102U needs Turn off the computers and the CS-102U. to be reset. Wait five seconds; turn the CS-102U on; turn the computers on. CS-102U is in Press the push button selection switch to Auto Scan mode. -
Page 14: Specifications
Specifications Function Specification Computer Connections Port Selection Push Button Switch LEDs 2 - Selected Port Connectors USB Type A 4 - USB Peripherals USB Type B 2 - Link to Computers Video 1 x HDB-15 Female - Console 2 x HDB-15 Male - Link to Computers Power 1 x DC 5V Jack Power Consumption... -
Page 15: Limited Warranty
Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FROM THE DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK OR ITS DOCUMENTATION. The direct vendor makes no warranty or representation, expressed, implied, or statutory with respect to the contents or use of this documentation, and specially disclaims its quality, performance, merchantability, or fitness for any particular purpose.
