Page 2: Background - The Evolution Of Kvm Switches
Background – The Evolution of KVM Switches KVM (Keyboard-Video monitor-Mouse) switches are a mature feature in modern data centers and now are common in the SOHO (Small Office/Home Office) desktop environment. Originally developed in the early 1990s as Keyboard-Video monitor (KV) switches, and updated to include Mice when graphical operating systems with mouse-controlled GUIs (Graphical User Interfaces) became popular in the mid 1990s, the KVM switch continues to offer the benefits of both space and power savings. -
Page 3: How Edid Works
How EDID Works EDID is now used by many computer graphic cards and monitors. EDID is defined by the international video standards group VESA (Video Electronics Standards Association). EDID involves a ROM chip in the video display which stores pertinent video data about that monitor in such a way that it can be “read”... -
Page 4: Aten Video Dynasync
KVM switch or extender. ATEN calls this technology Video DynaSync™ or VDS. VDS automatically maintains optimal video resolution for the majority of operating systems and is optimized for Windows 7. - Page 5 EDID so it is still able to get the needed EDID data. ATEN also provides a non-volatile memory to save the EDID that it detected the last time it was used so that, when powered up the next time, the chances are the KVM switch will already have the correct monitor EDID –...
-
Page 6: Aten Models Using Video Dynasync
ATEN Models using Video DynaSync™ In response to the trend toward LCD monitors with EDID, including those with conventional HDB-15 (VGA) video connectors, DVI connectors and HDMI connectors, ATEN has begun introducing KVM switches that incorporate our patented Video DynaSync™ technology. VDS eliminates boot-up display problems and automatically optimizes resolution when switching between ports. - Page 7 ATEN’s Petite™ series of miniature KVM Switches with Video DynaSync™ is an example of a two or four-computer KVM switch with integrated VGA/DVI, USB and speaker cables. It’s a good choice for the individual user who works with up to four computers, perhaps a desktop and a notebook model, and wishes to share one monitor, keyboard and speaker system.
- Page 8 connections. Computer selection is done via front panel pushbuttons or a multilingual OSD (On Screen Display) function. They have high-resolution (2048 x 1536 pixel) HDB-15 video and USB keyboard/mouse connections as well as speaker and microphone connections and a USB hub for excellent multi-media capability.
- Page 9 The CS1308 and CS1316 are, respectively, 8- and 16-port KVM switches that support both USB and PS/2 connections for the console and computers. As many as 16 additional switches can be cascaded (cabled one to the other) bringing the total number of connected computers that can be controlled from a single keyboard-monitor-mouse console to 64 (CS1308) or 256 (CS1316).
- Page 10 Phone: +44-1753-539-121 Fax: +44-1753-215-253 www.aten.co.uk E-mail: sales@aten.co.uk © Copyright 2009 ATEN International Co., Ltd. ® ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners.
