- Page 3 The complete Master View package consists of: One Master View Pro KVM Switch (CS-1004, CS-1008, or CS-1016) One Power Adapter One User Manual Check to make sure that the unit was not damaged in shipping. If you encounter a problem, contact your dealer.
-
Page 4: Table Of Contents
Limited Warranty ..........26 CS-1004 / CS-1008 / CS-1016 User Manual... -
Page 5: Overview
PC as well as saving all the space they would take up. It also eliminates the inconvenience and wasted effort involved in constantly moving around from one PC to another. CS-1004 / CS-1008 / CS-1016 User Manual Maximum via Daisy Chain 2001-01-13... -
Page 6: Features
Supports High Quality CS Series Custom Connector Cables Rack Mountable in 19" System Rack Hot Pluggable - Add or Remove PCs for Maintenance Without Powering Down the Switch Audio Support Built In Supports DDC2B CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 7: Hardware Requirements
Serial-to-PS/2 adapter at the end that plugs into the Master View. Therefore attempting to use a standard cable extender with adapters at both ends will fail. CS-1004 / CS-1008 / CS-1016 User Manual CS Custom Cable 2L-1701P + Keyboard & Mouse Adapters... -
Page 8: Unpacking
Port1 / Port2 switch combina- tion for three seconds. 4. Power LED Lights to indicate that the Master View Pro has been turned On and is receiving power. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 9: Cs-1016 Rear View
Link is reserved and has no function at this time. 6. Console Port Section If this is a first station unit, your monitor, keyboard and mouse plug in here. 7. Microphone and Speaker Jacks Your microphone and speakers plug in here. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 10: Installation
5. Plug the power adapter into an AC source; plug the power adapter cable into the Master View Pro’s Power Jack. PS/2 PS/2 KEYBOARD MOUSE PORT PORT PS/2 MOUSE PS/2 KEYBOARD VGA MONITOR DIP Switch Power Adapter VGA MONITOR PORT CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 11: Daisy Chaining
23 for Dip Switch Station Setting details). 3. Set DIP Switches 1 - 5 of the of the Second (Third, Fourth, etc.), Station Master View Pro according to the table provided on page 23. CS-1004 / CS-1008 / CS-1016 User Manual Indication Internal RAM Memory Error... - Page 12 (i.e., start with the last unit in the chain and work back to the First Station). b) Turn on the power to all the Master View Pro Stations before turning on the power to any of the PCs. PS/2 MOUSE MONITOR PS/2 KEYBOARD CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13...
-
Page 13: Operation
Note: It is not necessary to shut down and restart any of the stations or computers above the station you powered off. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 14: Port Selection
Note: Hot Key port selection under OSD is only enabled when DIP Switch 6 is set to ON. The next section describes the Port ID numbering system. Hot Key and OSD operation are explained in detail in the sections that follow it. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 15: Port Id Numbering
Port ID of the Station that is currently accessed. As in: 3 [Enter] which switches to the PC attached to CPU Port 3 of the Master View Station that is already being accessed. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... - Page 16 First two for Station Number; second two for Port Number First two for Station Number; third for Port Number Port Number on the Currently Active Station Port Number on the Currently Active Station Meaning CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13...
-
Page 17: Hot Key Operation
Number keys must be pressed from the regular keyboard; not from the numeric keypad. The keys must be pressed and released one key at a time. The interval between key presses cannot be longer than 6 seconds. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... - Page 18 Next available computer, you will circle back to Station 1 to start looking for the next available computer, and vice versa when switching backwards to an available computer that exists prior to the current one. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13...
-
Page 19: Osd Operation
Click on (éê) to move up or down through the list one screen at a time To activate a port, move the Highlight Bar to it then press [Enter] or Double Click with the left mouse button. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 20: Osd Main Menu Headings
To return to the OSD Main Menu without making a choice, press [Esc]. Explanation CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... - Page 21 Lists only the ports that have been selected for Quick View QVIEW + NAME scanning (see F4, below), and have been assigned names (see F5, below). Lists only the ports that have been assigned names (see F5, NAME ONLY below). CS-1004 / CS-1008 / CS-1016 User Manual Meaning 2001-01-13...
- Page 22 Case does not matter; OSD displays the Port Name in all capitals no matter how they were keyed in. 4. When you have finished editing, press [Enter] to have the change take effect. To abort the change, press [Esc]. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13...
- Page 23 While the settings are being cleared, a VALUES message appears on the display to indicate so. After the settings have been cleared, another message appears to indicate that the procedure completed successfully. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13...
- Page 24 Factory Default Settings The factory default settings are as follows: Setting Display Duration Always On Display Mode The Port Number plus the Port Number Scan Duration 5 Seconds Default CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13...
-
Page 25: Osd Security Features
Note: To modify or delete a previous password, use the backspace key to erase individual letters or numbers, or, with the cursor at the beginning of the password press the [Spacebar] to erase the entire password at once. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 26: Lock/Unlock Console
Note: To indicate that the console has been locked, the following symbol appears in front of the PORT ID DISPLAY on the monitor: [z CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 27: Station Numbering Table
Master View Pro’s rear panel are used to set the Station Number of each daisy chained unit, as indicated in the table below; (0 = On; 1 = Off): Station SW1 SW2 SW3 SW4 SW5 Station SW1 SW2 SW3 SW4 SW5 CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 28: Troubleshooting
First Stage unit for 3 seconds. Console Keyboard Port, then plug it back in. seconds. simultaneously pressing Buttons 1 and 2 on the First Stage unit for 3 seconds. Console Mouse Port, then plug it back in. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13... -
Page 29: Specifications
0 - 80% RH, Noncondensing Housing Metal Weight 2650g 483 x 150 x 89 mm (19" Dimensions (L x W x H) CS-1004 / CS-1008 / CS-1016 User Manual CS-1004 CS-1008 CS-1016 600mA 800mA 1 6 D B 2 5... -
Page 30: Federal Communications Commission Statement
The direct vendor also reserves the right to revise or update the device or documentation without obligation to notify any individual or entity of such revisions, or update. For further inquires please contact your direct vendor. CS-1004 / CS-1008 / CS-1016 User Manual 2001-01-13...
