Table 1: Trane zone sensor options
BAS order
Use
number
4190 1087 Any
4190 1088 Any
4190 1090 Heat pump
4190 1094 Heat pump
4190 1095 Unit vent
4190 1115 Fan coil
4190 1116 Unit vent
4190 1117 Any
Figure 4: Zone sensors compatible with Tracer zone controllers
10

Zone sensor options

Zone sensors are available in a variety of
configurations. Table 1 describes Trane
zone sensors available for Tracer zone
controllers. Figure 4 shows three types
of zone sensors for the Tracer ZN511
and ZN521 zone controllers.
Fan
High Med Low Auto
x x
x x x x
x x x
x
Zone
Setpoint Temperature
Off
thumbwheel sensor
x
x
x x
x x
x x x
x x x
x x x
x x x
Timed override
buttons
Comm jack
On Cancel
x x x
x x x
x
x x x
x x x
x x x
x x x
