Paper

This chapter describes the types and characteristics of the paper you can use in
your printer.
Types
Best results are obtained using good quality plain office paper, which has a paper
weight of between of standard sheets>15.5 and 24 lbs. Using 21 lbs. paper, you can
load up to 40 sheets in the ASF.
capacity is 10 sheets).
Sub-standard paper can affect the quality of printing.
Make sure the paper is inserted in the paper tray so as to print on the right face
of the page (see indication arrow on paper wrapping).
Printing on both sides of the paper may increase the risk of misfeeds or paper
jams.

Dimensions

The following table contains the dimensions of the types of paper
and envelopes which you can use in your printer:
Single Sheets
(width x length)
A4 210 x 297 m
8.26 x 11.7 in
A5 210 x 148.5 mm
(horizontal) 8.26 x 5.85 in
US Letter 8.5 x 11 in
215.9 x 279.4 mm
US Legal 8.5 x 14 in
215.9 x 355.6 mm
US Exec 7.25 x 10.5 in
184.2 x 266.7 mm
User-defined 105 x 80 mm, min.
4.134 x 3.15 in
220 x 356 mm, max.
8.26 x 16 in

Insertion

Automatic feed

The following documents can be inserted automatically from the ASF:
standard format single sheets (up to 40 x 80 g/m2sheets),
standard format coated paper (average 20 sheets),
standard format thicker paper/envelopes ( weight from 90 to 110<N>g/m2in packs
of not more than 10 pieces).

Semi-automatic feed

The following documents are inserted semi-automatically (loaded one at a time in
the ASF one at a time and inserted for printing using the Form Feed key):
user-defined documents,
special glossy paper,
transparencies.
Use only paper-backed transparencies (or film) specifically indicated for
ink-jet printers (e.g. 3M CG-3480).
For thicker documents (over 24 lbs.), the ASF
Envelopes
(width x length)
COM-10
DL
C5
C6
B5
B6
104.7 x 241.3 mm
4.125 x 9.5 in
110 x 220 mm
4.33 x 8.66 in
162 x 228mm
6.37 x 9 in
114 x 162 mm
4.4 x 6.37 in
176 x 250 mm
6.92 x 9.84 in
125 x 176 mm
4.92 x 6.92 in
