Administrator's Guide SoundPoint IP / SoundStation IP
Key
IP 301
ID
Function
37
n/a
38
n/a
39
n/a
40
n/a
41
n/a
42
n/a
Note
Assigning a VLAN ID Using DHCP
C - 14
IP 320 &
330
IP 430
Function
Function
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
The SoundPoint IP 550 has only the top four lines keys. Key IDs 31 and 42 are not
used on the SoundPoint IP 550 platform.
To assign a VLAN ID to a phone using DHCP:
In the DHCP menu of the Main setup menu, set VLAN Discovery to
>>
"Fixed" or "Custom".
When set to "Fixed", the phone will examine DHCP options 128,144, 157
and 191 (in that order) for a valid DVD string.
When set to "Custom", the value set in "VLAN ID Option" will be
examined for a valid DVD string.
DVD string in the DHCP option must meet the following conditions to be
valid:
— Must start with ?VLAN-A=? (case-sensitive)
— Must contain at least one valid ID
— VLAN IDs range from 0 to 4095
— Each VLAN ID must be separated by a ?+? character
— The string must be terminated by a ?;?
— All characters after the ?;? will be ignored
— There must be no white space before the ?;?
IP 550, 600,
IP 501
601, & 650
Function
Function
Transfer
Transfer
Headset
Headset
MicMute
Handsfree
Handsfree
Hold
n/a
Line4
n/a
Line5
IP 4000
Function
n/a
n/a
n/a
n/a
n/a
n/a
