Controls
C|ock
and Timer Coutro| (select models)
Ignition System
Your cooktop will feature either a pilot
ignition or pilotless ignition. If the gas
supply to the range is turned off, be sure all
controls are set in the OFF position before
re-supplying gas to the appliance.
NOTE: The display will flash when electrical power is first supplied to the
appliance or if there has been a power failure.
To Set the Clock:
1. Press the Clock pad.
• A beep will sound when the Clock
pad is pressed.
2. Press or press and hold the A or _' pad
until the correct time of day appears in
the display.
• Press to change the time in one
minute increments.
• Press and hold to change the time
in 10 minute increments.
To recall the time of day when the timer is
displayed, press the Clock pad.
To Set the Timer:
The timer can be set from one minute
(0:01) up to 12 hours (12:00). The timer
does NOT control the oven.
1. Press the Timer pad.
• A beep will sound when the Timer
pad is pressed.
• 0:00 will appear in the display.
2. Press or press and hold the A or V pad
until the correct time appears in the
display.
• Press to change the time in one
minute increments.
• Press and hold to change the time
in 10 minute increments.
• Timer will start automatically after a
few seconds. The flashing colon indi-
cates that the timer is in use.
• If the Clock pad is pressed, the
colon will continue to flash to indi-
cate the timer is in use.
3. A beep will sound at one minute (0:01).
4. At the end of the timer operation, 0:00
will appear in the display and three beeps
will sound.
• One beep will sound every 10
seconds for 10 minutes or until the
timer operation is cancelled.
To Cancel the Timer:
Press the Timer pad and the current time
of day will reappear in the display.
NOTE: When 0:00 is displayed, pressing
either the Timer or Clock pad will also
cancel the timer operation.
Surface Coutro|s
Pilotless Ignition (select
models)
Pilotless ignition eliminates the need for a
constant standing pilot light. There are
two ignitors for conventional surface burn-
ers. Each sealed burner has a spark ignitor.
When cleaning around the surface burner
use care. If cleaning cloth should catch the
ignitor, it could
Sealed Gas Burner
damage it pre-
venting ignition. _ ........ - _.EAo
If the surface (_'_::---a_'')
burner does ..... __.:#_ j
not light, check "_p!-- -- _-_--'-
if ignitor is broken, _...............
soiled or wet. If clogged, clean the small
port beneath the ignitor using a straight
pin.
Pilot Igteition (select
models)
When the range is first installed, the stand-
ing pilots may be difficult to light due to air
in the gas line. To bleed off air from the
line, hold a lighted match next to the burner
and turn the knob on. When the burner
lights, turn the knob off and proceed as
directed below.
To light pilot:
Raise the cooktop and
hold a lighted match near the pilot ports
(See illustration). There are two pilot ports,
one on the right side and one on the left
side.
Conventional
Gas Burner
