SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION
INSTRUCTIONS
Model 89291A For Trimmer T242
WARNING!
Minimize the risk of injury to yourself and others! Read the Owner's/Opera-
tor's manual originally supplied with the unit that is being upgraded and
familiarize yourself with the contents. Always wear eye and hearing protec-
tion when operating your unit.

Advertisement

loading

Related Manuals for Shindaiwa 89291A

Summary of Contents for Shindaiwa 89291A

  • Page 1 SHINDAIWA GRASS TRIMMER TO BLADE CONVERSION INSTRUCTIONS Model 89291A For Trimmer T242 WARNING! Minimize the risk of injury to yourself and others! Read the Owner's/Opera- tor's manual originally supplied with the unit that is being upgraded and familiarize yourself with the contents. Always wear eye and hearing protec- tion when operating your unit.

  • Page 2: Table Of Contents

    Always wear a harness The instructions described in this manual are intended to help when operating this unit you get the most from your Shindaiwa power tool as well as with a blade. A harness is also recommended when to protect you and others from harm. These procedures are using trimmer line.

  • Page 3: General Safety Instructions

    Safety Labels IMPORTANT! Safety and Operation Information Labels: Make sure all information labels are undamaged and readable. Immediately replace damaged or missing information labels. A new label is provided in this kit and additional labels are available from your local authorized Shin- daiwa dealer.

  • Page 4: Kit Contents

    Kit Contents Description Warning Label Debris Shield Debris Shield Extension M5 x 45 mm SPW Bolt Upper Clamp Spacer Shoulder Strap Hanger M5 x 12 mm Socket Head Cap Screw M5 Nut M5 x 35 mm SPW Bolt Barrier Bar – 4 Hole M5 Nut 4 Bolt Guard M7 x 20 mm SW Bolt...
  • Page 5 Remove Gear Case 1. Remove gear case locating screw (D) and loosen gear case clamp (E). 2. Remove gear case from outer tube. Remove Handle Assembly T242 with 1-screw Handle 1. Remove handle assembly. Retain all parts for future use. Remove Handle Assembly T242 with 4-screw Handle 1.
  • Page 6 Install Hanger 1. Position the hanger (A) on the outer tube (B) between the handle and throttle assembly and secure the hanger with the nut (C) and bolt (D). Install Handle and Barrier Bar T242 with 1-screw Handle 1. Install Handle and Barrier Bar. 2.
  • Page 7 Install Gear Case 1. Install gear case onto outer tube. Align locating hole on gear case with locating hole in tube. 2. Install locating bolt (A) and tighten clamp bolt (B). Install New Cutting Attachment Shield Assemble the Cutting Attachment Shield to the Outer Tube. 1.
  • Page 8 Installing Brushcutter Blade Gear Case with notched flange: 1. Turn the unit over so that the gearcase output shaft faces UP. 2. Align the hole in the holder with the notch in the gearcase flange, and then temporarily lock the output shaft by inserting a hex wrench through both holes.
  • Page 9 Gear Case with side-mounted locking tool hole: 1. Turn the unit over so that the gearcase output shaft faces UP. 2. Align the notch in trimmer head holder (F) with the notch in the gear case flange. Lock the holder and output shaft by inserting a hex wrench through the locking hole in the gear case and into the aligned notches.
  • Page 10 Gear Case with side-mounted locking tool hole and grooved output shaft: 1. Turn the unit over so that the gearcase output shaft faces UP. 2. Align the notch in trimmer head holder (F) with the notch in the gear case flange.
  • Page 11 WARNING! A standard grass trimmer unit with loop handle should NEVER be operated with blade-type attachments. For blade use, the trimmer must be fitted with a bicycle-type handlebar or barrier bar that is located in front of the operator to reduce the risk of the operator coming in contact with the cutting attachment.

  • Page 12: Using A Brushcutter Blade

    Using A Brushcutter Blade WARNING!  Before working with a blade-equipped unit, always inspect and clear the area of objects that could interfere with or damage the blade.  Never use a blade near sidewalks, fence posts, buildings or other objects that could cause injury or damage. ...
  • Page 13 NOTES...
  • Page 14 NOTES...
  • Page 15 NOTES...
  • Page 16 If you require assistance or have questions concerning the application, operation or maintenance of this product you may call the Shindaiwa Consumer Product Support Department at 1-877-986-7783 from 8:30 am to 4:30 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial number of your unit.
