X7502235600
07/10
SHINDAIWA GRASS TRIMMER
SHIELD UPGRADE INSTRUCTIONS
Model 80561
For all Grass Trimmers
22T, T230, T231, T260, T261, T270, T350,
65001 Multipurpose Trimmer Tool
EARLY SHIELD
WARNING!
Minimize the risk of injury to yourself and others! Read the Owner's/Opera-
tor's manual originally supplied with the unit that is being upgraded and
familiarize yourself with the contents. Always wear eye and hearing protec-
tion when operating your unit.
NEW SHIELD
Advertisement
Related Manuals for Shindaiwa 80561
Summary of Contents for Shindaiwa 80561
- Page 1 SHINDAIWA GRASS TRIMMER SHIELD UPGRADE INSTRUCTIONS Model 80561 For all Grass Trimmers 22T, T230, T231, T260, T261, T270, T350, 65001 Multipurpose Trimmer Tool EARLY SHIELD NEW SHIELD WARNING! Minimize the risk of injury to yourself and others! Read the Owner's/Opera- tor's manual originally supplied with the unit that is being upgraded and familiarize yourself with the contents.
-
Page 2: Attention Statements
The instructions described in this manual are intended to help you get the most from your Shindaiwa power tool as well as to protect you and others from harm. These procedures are guidelines for safe operation under most conditions, and are not intended to replace any safety rules and/or laws that may be in force in your area. -
Page 3: General Safety Instructions
WARNING! WARNING! Use only authorized Shindaiwa parts and accessories with your Shindaiwa trimmer. Do not make modifica- Never operate power equipment of any kind if you tions to this unit without the written approval of Echo, are tired or if you are under the influence of alcohol, Inc. - Page 4 The Properly Equipped Operator Wear close-fitting clothing to protect legs and arms. Gloves Wear hearing protection devices offer added protection and are and a broad-brimmed hat or helmet. strongly recommended. Do not wear clothing or jewelry that could get caught in machinery or underbrush.
- Page 5 Be Aware of the Working Environment (all units) Make sure bystanders or ob- servers outside the 50-foot “dan- Avoid long-term opera- ger zone” wear eye protection. tion in very hot or very cold weather. Reduce the risk of bystanders being struck by flying debris.
- Page 6 Kit Contents FITS MODELS T230, T231, Description T260, T261, T270, T350 65001, 22T Warning Label Debris Shield Debris Shield Clamp Bolt Debris Shield Upper Clamp Cutting Attachment Shield Mounting Plate 24 mm (small) Outer Tube Shim 24 mm (thick) Clamp Bolt (small) D-Washer (small) Flat Washer (small) Retaining Nut (small)
- Page 7 Assembly Removing the Old Cutting Attachment Shield Remove the Existing Cutting Attachment Shield. IMPORTANT! IMPORTANT! Socket-Head You must know the model designation of the unit before Cap Screws you begin. Some units have an outer tube of a different diameter so the correct size parts must be used to secure Shim Bracket the shield properly.
- Page 8 New Grass Trimmer Cutting Attachment Shield Assemble the Cutting Attachment Shield to the Outer Tube. Socket- Head Cap Outer 1. Choose the shims and shield mount- Screw Tube ing plate hardware that matches your Bracket model designation. See Contents List for model references.
- Page 9 NOTES...
- Page 10 NOTES...
- Page 11 NOTES...
- Page 12 If you require assistance or have questions concerning the application, operation or maintenance of this product you may call the Shindaiwa Consumer Product Support Department at 1-877-986-7783 from 8:30 am to 4:30 pm (Central Standard Time) Monday through Friday. Before calling, please know the model and serial number of your unit.
