I Microphone keypad

KEY FUNCTION
Switches between opening and closing the
squelch.
Starts and stops scanning.
Starts and stops priority watch.
Selects high output power.
Selects mid. output power.
Selects low output power
Selects minus duplex operation.
Selects plus duplex operation.
Selects simplex operation.
Increases audio output level.
SECONDARY FUNCTION (
In memory mode enters bank selecting
(p. 15) condition.
(p. 40) Starts and stops tone scanning.
(p. 46) Turns the one-touch PTT function ON and
OFF.
(p. 17) Turns the DTCS squelch ON.
(p. 17) Turns the DTCS pocket beep function ON.
(p. 17) Turns the DTMF memory encoder function
ON.
(p. 21) Turns the subaudible tone encoder ON.
(p. 21) Turns the CTCSS pocket beep function
ON.
(p. 21) Turns the tone squelch function ON.
(p. 15) Sends a 1750 Hz tone signal while pushing
and holding.
PANEL DESCRIPTION
+key) OTHER FUNCTIONS
(p. 35)
(p. 54)
(p. 18)
(p. 53)
After pushing :
Transmits the appropriate
(p. 52)
DTMF code. (pgs. 23, 49)
When the DTMF memory en-
(p. 49) coder is activated, push [0] to
[9] to transmit the appropriate
DTMF memory contents.
(p. 21)
(p. 52)
(p. 53)
(p. 23)
1
1
(p. 49)
8
