4 Channel H.264 DVR
Model: QSD9004CM
What's in the box?
check that your package includes the following
PWR
HDD
CH1
CH2
CH3
CH4
QUAD
PTZ
4 C h a n n e l D i g i t a l
V i d e o R e c o r d e r
REW
PAUSE
PLAY
FWD
STOP
REC
4 Channel DVR
Ethernet Cable
Remote Control
Cameras x2 - QSC7614
x2 - QSC7614W
Software CD
Manual
Power Supply for DVR
60 FT. Cables x 4
Power Supply and 4 Way
Splitter for Cameras
Hard Drive (Pre-Installed)
BNC to RCA Cable
:
USB Mouse
