Grizzly G8122 Instructions

Always wear safety glasses
or a face shield during use
to prevent injury.
When servicing, always dis-
connect tool from air to pre-
vent unexpected operation.
Exceeding this PSI may
result in injury/tool damage.

Specifications

No-Load Speed ............................... 18,000 RPM
Wheel Size ............................. 3" Dia. x
Air Inlet ....................................................
Average Air Consumption .......................... 4 cfm
Weight .........................................................2 lbs.
Operation
Connect to air and press the trigger to operate. To
reduce the risk of injury, always keep the safety
guard installed for all operations.

Replacing Wheels

Use the included wrenches to replace the cut-off
wheels. Do not use cracked wheels or they might
fly apart during operation. Only use wheels rated
for 18,000 rpm or higher. Make sure wheels are
installed so the rotation direction on the wheel and
saw match. Make sure the washer is reinstalled
between the cut-off wheel and the cap screw.
Lubrication
To improve tool lifespan, use a filter/lubricator/
regulator setup as shown in Figure 2. Otherwise,
lubricate multiple times daily with 2–3 drops of
pneumatic tool oil. Place the oil directly into the air
fitting as shown in Figure 3.
EYE INJURY HAZARD!
INJURY HAZARD!
90 PSI
MAX AIR PRESSURE!
⁄
3
8
⁄
1
AIR CUT-OFF SAW
" Arbor
Your
" NPT
Tool
4
Figure 2. Installing a filter/lubricator/regulator to
Figure 3. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
MODEL G8122
INSTRUCTIONS
Figure 1. Model G8122.
Quick
Quick
Lubricator
Connector
Connector
Quick
Coupler
Quick
Air Hose
Coupler
improve the lifespan of your tool.
Regulator
Air
Compressor
Filter
