User's Manual
Analog Computer-Video Interface
RGB 190F
RGB 192
RGB 198
68-647-01 Rev. C
Printed in USA
10 04
Advertisement
Table of Contents
Related Manuals for Extron electronics RGB 190F
Summary of Contents for Extron electronics RGB 190F
- Page 1 © 2004 Extron Electronics. All rights reserved. User’s Manual Extron Electronics, Japan Daisan DMJ Building 6F 3-9-1 Kudan Minami Chiyoda-ku, Tokyo 102-0074 Japan +81.3.3511.7655 Fax +81.3.3511.7656 RGB 190F RGB 192 RGB 198 Analog Computer-Video Interface 68-647-01 Rev. C Printed in USA 10 04...
- Page 2 Precautions Safety Instructions • English Warning This symbol is intended to alert the user of important Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main operating and maintenance (servicing) instructions power system with a grounded (neutral) conductor.
-
Page 3: Table Of Contents
Appendix • Reference Information Specifications ... A-2 Included Parts ... A-5 Optional Accessories ... A-6 Cables ... A-7 RGB 190F, RGB 192 and RGB 198 • Table of Contents ... 1-2 ... 2-1 ... 2-10 2-10 2-11 2-11 ... A-1... -
Page 4: Chapter 1 • Introduction
About the RGB 190F, RGB 192 and RGB 198 Features 68-647-01 Rev. C Printed in USA 10 04 All trademarks mentioned in this manual are the properties of their respective owners. RGB 190F, RGB 192 and RGB 198 • Table of Contents... -
Page 5: About This Manual
About the RGB 190F, RGB 192 and RGB 198 The RGB 190F, RGB 192 and RGB 198 are analog computer- video interfaces with 300 MHz (-3dB) video bandwidth and Digital Display Sync Processing™ (DDSP™). Figure 1-1 shows a typical RGB 198 application;... -
Page 6: Chapter 2 • Installation And Operation
Use the serration pulse switch if flagging or bending occurs at the top of the video display. RGB 190F, RGB 192 and RGB 198 • Introduction RGB 190F, RGB 192 Chapter Two... -
Page 7: Installation Overview
This is an overview of the installation process. You will find detailed installation and operation instructions in this chapter. Install and set up the RGB 190F, RGB 192 or RGB 198 interfaces by following these basic steps: Turn off all of the equipment (computers, remote controls, interface, projector/monitor, local monitor and speakers or other audio device). -
Page 8: Rack Mounting (Rgb 198 Only)
Install blank panel(s) or other unit(s) on the rack shelf. Attach the rack shelf to the rack using the supplied bolts. RGB 190F, RGB 192 and RGB 198 • Installation and Operation 6" Deep Rack Shelf 1/4 Rack Width Front False... - Page 9 DDSP disables the interface’s Horizontal Shift control. To use the display’s centering controls instead of the interface’s controls, set the DDSP DIP switch to On. RGB 190F, RGB 192 and RGB 198 • Installation and Operation 125V 50/60 Hz 5A...
- Page 10 On — ID bits 4 and 11 are tied to ground. Off — ID bits 4 and 11 are unterminated. 6 — Mono audio output (RGB 192 only, spare on RGB 190F) On — Monaural audio is output on the left channel only.
-
Page 11: Operation And Troubleshooting
4) On (up) or Off (down) on the front panel. 2-10 RGB 190F, RGB 192 and RGB 198 • Installation and Operation To test the system setup and output, substitute a video test generator for the computer input. Unplug the input and output devices’... -
Page 12: Specifications
Installation and Operation, cont’d RGB 190F, RGB 192 A ppendix A Reference Information Specifications Included Parts Optional Accessories Cables RGB 190F, RGB 192 and RGB 198 • Installation and Operation 2-12... - Page 13 Input level ... 2.0 V to 5.5 Vp-p with ±0.2 VDC offset (max.) Output level ... 4.0 V to 5.0 Vp-p, unterminated RGB 190F, RGB 192 and RGB 198 • Reference Information Input impedance ... 510 ohms Output impedance ... 75 ohms Max.
-
