SIP Installation and Removal
To install a SIP, see
Attach an ESD-preventive wrist strap and follow its instructions for use.
Step 1
Remove the SIP from its antistatic packaging.
Step 2
Remove the PLIM or PLIM impedance carrier from the slot you need to fill and set it aside.
Step 3
Note
Grasp one of the septums that separate the SPA slots or one of the ejector levers with one hand and place
Step 4
your other hand under the SIP to support and guide it into the correct slot. Slide the card halfway into
the correct slot. Avoid touching the card circuitry or any connectors.
Pivot both card ejector levers so the openings on the card ejector cams at the top and bottom of the SIP
Step 5
pass over the tabs on each side of the card cage slot.
Caution
Continue sliding the SIP into the card cage slot until the openings on the card ejector cams engage the
Step 6
tabs on each side of the card cage slot.
Note
To seat the card in the midplane connector, grasp both card ejector levers and pivot them inward toward
Step 7
the handle in the card carrier until they are flush against the front edge of the card carrier.
Engage both captive screws on the PLIM, and then tighten the screws. Tighten the locking thumbscrews
Step 8
on both sides of the SIP to a torque of between 8.3 and 11 inch-pounds (94 to 124 N-cm). Do not
overtighten.
Caution
Caution
Install the SPAs. See the
Step 9
Install the interface cables. We recommend that you clean the fiber-optic connections before attaching
Step 10
the cables. See
instructions.
Cisco CRS-1 Carrier Routing System SIP and SPA Hardware Installation Guide
5-6
Figure 5-4 and follow these steps:
Remove only one PLIM impedance carrier and install one SIP at a time. Be sure to verify that
each SIP is fully installed and secured before installing another card.
Verify that the openings on the card ejector cams pass over the tabs; otherwise, one or both
ejector levers might bind when you attempt to close the ejector levers, thereby damaging or
breaking one or both ejector levers.
Guide pins exist that make initial contact with the backplane connector as you slide a SIP into
its slot. After the guide pins make contact, continue pushing on the SIP until the card ejector
levers begin pivoting forward, toward the front panel on the SIP.
Be sure to engage both captive screws on the SIP before you begin to tighten the screws;
otherwise, the SIP might not seat properly.
To ensure adequate space for additional PLIMs or SIPs, always tighten the captive screws on
each newly installed PLIM or SIP before you insert another one. These screws also prevent
accidental removal and provide proper grounding and EMI shielding for the system.
"SPA Installation and Removal" section on page
Cisco CRS-1 Carrier Routing System Fiber-Optic Cleaning Guide
Chapter 5 Installing and Removing a SIP
6-2.
for cleaning
