- Page 1 1/3” 520TVL High-Res. Color Camera(350HQ/550) 1/3” 380TVL High-Res. Color Camera(250)
- Page 2 Notice This manual is presented to users of the EQ series by EverFocus Electronics Corporation. With years of engineering research, EverFocus has spared no effort in manufacturing high quality products to users worldwide, and maintains a policy for continual product improvement. Therefore, EverFocus reserves the right to revise and improve products, their specifications and documentation without notice.
-
Page 3: Table Of Contents
Table of Contents Safety Warning ……...……………………………………3 Introduction……………………………………………….4 Specification……………………………………………….5 Major Parts and Their Functions………………….…….6 Installation Instructions……………………………..…. 11... -
Page 4: Safety Warning
Safety Warning 1. Handle camera with care. Be careful when handling the camera, do not drop it or subject it to strong shock or vibration to prevent any damages to it. Do not disassemble it or place it on an unstable base. 2. -
Page 5: Introduction
The new 350 HQ series is a solid-state color video camera specifically designed for high quality surveillance applications. It incorporates break through DSP technology that provides the most reliable and accurate color picture in the security industry. The camera is convenient to use with C-mount or CS-mount lenses and an easy back-focus adjustment helps efficient installation. -
Page 6: Specification
Specifications Model 1/3” interline transfer color CCD Pickup Device: NTSC / PAL Video Format: NTSC: 510 Picture Element: PAL: 500(H) x 580(V) Horizontal 380TV lines Resolution: Sensitivity: 0.5lux/F=1.2 Video Output: BNC VBS 1.0Vp-p, 75ohm S/N Ration: Over 48dB Electronic Up to 1/100,000 Shutter: Back Light ON/OFF switch... -
Page 7: Major Parts And Their Functions
Major Parts Names and Their Functions Front Side 12(optional) Rear Rear (EQ series) (EQ series” A”) - Page 8 1. Focal Length Adjustment Ring Use this ring to adjust the appropriate focal length according to the lens type. Rotate the ring clockwise for a CS-mount lens; rotate the ring counterclockwise for a C-mount lens. factory setting is C-mount. 2. Lens Mount Used to mount an appropriate C-mount or CS-mount lens.
- Page 9 ES (Electronic Shutter) Off/On ES ON: The camera continuously adjusts the shutter speed from 1/60 (NTSC),1/50 (PAL) second to 1/100,000 second according to the luminance conditions of the scene. ES OFF: The shutter speed is fixed at 1/60 (NTSC), 1/50 (PAL) second.
- Page 10 VD/DD (Auto Iris lens Type) For video drive auto iris lens, please set the switch to VD. For direct drive iris lens, set the switch to DD. The default setting is DD. Wire the lens cable to the lens connector according to the following table. Pin1 Pin2 Pin3 Pin4 Video Drive +12V GND VD-IRIS GND Direct Drive Cnt-Cnt+ Drv+ Drv-...
- Page 11 9. Video Output Connector BNC VBS 1.0 Vp-p, 75ohm 1 Power Cable (EQ series) 2 DC12V/AC24V Screw Terminals (EQ series “A”) 3 Audio Output(optional):Connect with an audio device, RCA connector...
-
Page 12: Installation Instructions
Installation Instructions 1) Remove the cap cover from the top of the lens mount. 2) To attach a C-mount/CS-mount lens, turn the focal length adjustment ring to the appropriate position. Note: If a C-mount lens is used, please make sure the focal length adjustment ring is set at C position before fixing the lens. - Page 13 China Office: Room 609, Technology Trade Building, Shandgdi Information Industry Base, Haidian District, Beijing,China TEL: +86-10-62971096 FAX: +86-10-62971432 www.everfocus.com.cn Japan Office: 1809 WBG MARIBU East 18F, 2-6 Nakase.Mihama-ku. Chiba city 261-7118, Japan TEL : +81-43-212-8188 FAX : +81-43-297-0081 www.everfocus.com MQ35G00900 P/N:...
