EverFocus EZ730 Specifications

EZ730
Outdoor True Day/Night IR Bullet Camera
Features
• Ultra resolution of over 720 horizontal TV lines for
astounding image quality
• Exview HAD II sensor delivers amazing ultra high
sensitivity of .05 lux – very low light sensitivity
without DSS low light boost - Zero Ghosting
guaranteed
• Varifocal 2.8~12mm lens with external zoom &
focus controls captures desired field of view
• Digital Wide Dynamic Range expansion to deliver
properly exposed images despite unbalanced
lighting in the scene
• Provides 2D-Noise Reduction to improve picture
clarity while enabling DVRs to improve disk storage
utilization
• Easy to use OSD setup menu
• Fully adjustable mount encloses/protects cable
from elements and deliberate tampering
• IP66 weather resistant rating means that it will
withstand the elements of outdoor conditions
• Up to 82 feet of IR distance
Dimensions: mm/in
145
120
224
Ordering Info
EZ730B: Day/Night IR Bullet, Black, 720+ TVL, 2.8-12mm
EZ730W: Day/Night IR Bullet, White, 720+ TVL, 2.8-12mm
2012 EverFocus Product Catalog Vs 1.1 - Models vary in different countries. Visit www.everfocus.com and select your country for additional ordering and specification information.
43
M12 XP1.0
82
Ф65
EverFocus is not responsible for typographical errors. Product specifications are subject to change without notice.
www.everfocus.com
U
720+
720
+
True D/N
Ultra Series
2D
DIGITAL
Noise
WDR
Reduction

Specifications

Part Number
Pickup Device
Video Format
Picture Elements
Effective Pixels (NTSC |
PAL)
Scanning System
Scanning Frequency
Horizontal Resolution
Sensitivity
Sensitivity IR on
S/N Ratio
Electronic Shutter
Video Output
Gamma Correction
Lens Type
Lens Options
BLC
Gain Control
White Balance
Sync Mode
IR LED
IR Wave Length
IR Distance
IR Configuration
Day/Night
OSD Menu
English, Spanish, French, Chinese, German, Japanese,
OSD Languages
Digital Noise Reduction
ATR
Wide Dynamic Range
Motion Detection
Privacy Mask
Environmental
Power Source
Power Consumption
Operating Temp
Humidity
Dimensions (in | mm)
Weight (lbs | gm)
Heater
Mount
Certifications
Analog Solutions
12VDC/
Weather
24VAC Heater
Resistant
Split Glass
IR
Isolation
Distance
Cable Prevents
82 Feet
Management IR Glare
Solution
EZ730
1/3" 960H Sony Exview HAD CCD II
NTSC or PAL
1020 x 508 (NTSC) | 1020 x 508 (NTSC)
976 x 494 (NTSC) | 976 x 582 (PAL)
2:1 Interlace
H: 15.734 KHz, V: 59.94 Hz | H: 15.625KHz, V: 50Hz
720+ TVL
0.05 lux/F1.2;
0 Lux
Over 50dB (AGC off)
1/60s~1/100,000s
BNC 1.0Vp-p 75Ω
0.45
2.8-12mm
Varifocal
OFF/BLC/HLC
Low light auto, bright light auto, manual selectable
ATW/One Push/User2/Anti-Crawl/Manual/Push Lock
Internal Sync
20 Invisible LEDs
940nm
Up to 82Ft/25M
Split glass isolation prevents internal reflections
Auto
Built-in joystick controller/inner key
Portuguese, Russian
2D On/Off (Level adjustable)
On/Off (3 levels each adjustable for luminance and
contrast)
On/Off (3 levels each adjustable for luminance and
contrast)
Off/On for 4 selectable zones (On screen indication on
alarm)
Off/On for 4 selectable zones
IP66 Weather Resistant
12VDC/24VAC
270mA 4.9W
14°F~122°F | -10°C~50°C
Less than 80% non-condensing
3.22 x 3.1 x 5.7 | 82 x 79.3 x 145
1.98 lbs | 900g
Yes, built-in
Mount Bracket Included
CE/FCC
OSD
