MERLIN LEGEND Communications System Release 5.0
System Manager's Guide 555-650-118
2
About the System
Programming the System
Programming the System
System installation includes programming features, settings, and options selected
by you or a representative from your company.
Depending on the feature, either you, as system manager, or a person at his or
her extension can make changes to features:
System Programming. Used to program systemwide or group features. A
Lucent Technologies technician can also do system programming. You use
one of the following:
— An MLX-20L telephone, referred to as the programming console
— A PC with System Programming and Maintenance (SPM) software,
Extension Programming. Can be performed in two ways:
— Centralized Telephone Programming. You program at the
— Telephone Programming. Either you or the user programs at a specific
When programming at an MLX telephone or PC, you work with features and
options from screen menus. You simply select an item from the menu and enter
settings as desired.
System Capacities
The system can support up to 80 line/trunk jacks, 72 of which can actually be
B-channels supplied on 100D modules or 800 NI-BRI modules (Release 4.0 and
later systems).
The maximum number of extensions depends on the type of equipment included
in the system. In theory, you can connect as many as 255 extensions, but this, in
fact, is not practical. In Release 4.0 and later systems, a higher-capacity tip/ring
(T/R) extension module, the 016, allows the system to support as many as 200
T/R devices such as single-line telephones, modems, and fax machines. The
number of extensions you can connect depends on the equipment you are using
in your system.
Appendix C describes hardware and software capacities, that is, the minimums
and maximums for certain features.
If you have any questions about your system's capacity, contact your Lucent
Technologies representative.
reaching the system in one of three ways: a direct connection between
the PC and the system's control unit, an on-site or local modem
connection to the modem in the control unit, or an off-site remote
modem connection.
programming console.
telephone.
2
2
Issue 1
June 1997
Page 2-25
