Note
To prevent unconnected leads from shorting out, insulate them
by wrapping their tips with electrical tape. Similarly, insulate the
ends of connected leads.
If an external amplifier is to be connected to the receiver, be
sure to ground its outside housing to the vehicle body (a metal
part).
Names of lead wires and destinations (refer to Page 71)
No. Name
1 ACC
2 B+
3 Ground
4 Antenna power supply Blue
5 Lamp power supply
6 Control power supply Blue/White
7 E-LAN terminal
8 & 9 Line-out terminals
10 Line-out terminals (Nonfader)
11 Speaker terminals
12 Cellular phone mute
Wire color Destination
Red Connect where the power comes on
when the ignition is in the ACC
position.
Yellow Connect where the power is
constantly available, regardless of the
ignition switch's position.
Black Connect
grounding is available.
Connect to the automatic-antenna
control terminal of the vehicle.
Orange/White Connect to where power comes on
when the headlights are turned on.
Connect to the control terminal for
the external amplifier, or to the RCA
output connectors of a DSP or EQ.
Connect to the E-LAN terminal of the
CD changer, DSP, etc.
Connect to the RCA input connectors
of an external amplifier.
Connect to the RCA input connectors of
a DSP or EQ, or the RCA connectors of
a woofer amplifier.
Connect them to their respective
speakers.
Pink Connect to the ground output
terminal on a mobile phone.
69
Mounting instruction
where good body
