IGNITER

Verify proper voltage at the positive (+) and ground (-)
terminals of the igniter. Remove high voltage cable fro
igniter. The igniter should produce a sparking sound during
trial-for-ianition. The igniter installed on the refrigerators as
original equipment is part number 2931132019 (RV Gas
Model 679). This igniter is rated 50 MA. This igniter may
also be used on any other model.
DO NOT install the Channel Mark 6, Model 12E Igniter
(shown below) as a service replacement part.
Installation of the Channel Products, Inc., Gasliter Mark 6, Model 12E will VOID the Warranty on
refrigerator.

HIGH VOLTAGE CABLE

Disconnect high voltage cable from electrode. If sparking starts during trial-for ianition, the cable is
good.

ELECTRODE

Do a visual check for cracks or breaks on the ceramic insulator. If either of the above is found, replace
the electrode. The spark gap must be set at three sixteenths (3/16") of an inch and tip of electrode
above the slots in the burner.
16
r
MARK 6, MODEL 12E
CHANNEL PRODUCTS
CHESTERLAND OH 44026
25mA
12VDC
