- Page 1 INSTRUCTION MANUAL DIGITAL BLOOD PRESSURE MONITOR CH-462E 0801...
-
Page 2: Table Of Contents
Contents 3 - GENERAL REMARKS 5 - PRECAUTIONS FOR USE AND MAINTENANCE 8 - UNIVERSAL DESIGN 9 - IDENTIFICATIONS OF PARTS 10 - LOADING THE BATTERIES 11 - USING AC ADAPTER (OPTION) 12 - REMOVING THE BATTERIES 12 - RESETTING OPERATION 13 - SETTING THE CLOCK 17 - MEASURING YOUR BLOOD PRESSURE 19 - TIPS FOR OBTAINING ACCURATE MEASUREMENTS... -
Page 3: General Remarks
GENERAL REMARKS General remarks on blood pressure and blood pressure measurement 1. To defl ate the cuff quickly, press the “START/STOP” switch. 2. The attached cuff is suitable for arm circumferences of 20-32 cm. 3. When attaching the cuff, the air hose should be placed on the inside of your arm on top of the artery. - Page 4 GENERAL REMARKS 9. DO NOT measure blood pressure when the cuff has been on your arm for a few minutes or more. During this time, your arm will have built up a higher blood pressure and you will not get valid reading. 10.
-
Page 5: Precautions For Use And Maintenance
PRECAUTIONS FOR USE AND MAINTENANCE Precautions for use 1. If you suffer from heart disease, high blood pressure or other circulatory disease, consult your physician before using the monitor. 2. If the cuff pressure feels abnormal or you experience any other irregularity while using the cuff, reduce the pressure immediately by pressing the “START/STOP”... - Page 6 PRECAUTIONS FOR USE AND MAINTENANCE 15. Be sure to use this unit only for measuring blood pressure. DO NOT use it for any other purpose. 16. DO NOT use this unit on infants. 17. Blood pressure measurement may not be possible for anyone with common arrhythmias such as atrial or ventricular premature beats or atrial fi...
- Page 7 The blood pressure measuring device is generally recommended to have the monitor inspected every two years to ensure correct functioning and accuracy. Please contact a distributor. CITIZEN SYSTEMS(H.K.) LIMITED FLAT A-B, 4TH FLOOR, HUNG MOU INDUSTRIAL BUILDING, 62 HUNG TO ROAD, KWUN TONG,...
-
Page 8: Universal Design
UNIVERSAL DESIGN This product has been developed with the concept of Universal Design to ensure safe and easy use for a broader range of users. The product’s shape and color was designed to portray “warmth” and “gentleness” and have functional qualities that compliment the human body, which make it “easy to understand,”... -
Page 9: Identifications Of Parts
IDENTIFICATION OF PARTS Component names Main Unit Date display Time display Systolic blood pressure Alarm icon display Cuff holding pocket Diastolic blood pressure display Pulse display Memory icon Measurement icon Battery icon Air hose socket START/STOP Switch MODE Switch a Stand-by SET Switch MEMORY Switch Cuff... -
Page 10: Loading The Batteries
LOADING THE BATTERIES (Batteries supplied with the unit should be loaded in compartment before putting the Blood pressure monitor in use.) Open the cover of battery compartment. Pressing the hook down, pull the cover toward you to open. Hook Battery compartment Battery compartment... -
Page 11: Using Ac Adapter (Option)
USING AC ADAPTER (OPTION) Using the optional dedicated AC adapter for the CITIZEN blood pressure monitor (CH-462E) allows you to measure your blood pressure without having to worry about the amount of remaining charge in the batteries. 1. Insert the AC adapter plug into... -
Page 12: Removing The Batteries
REMOVING THE BATTERIES • When the icon is displayed, or where the clock is no longer shown or nothing appears in the display, replace the old batteries with four new ones. All four batteries should be changed at once. • The memory is erased if the batteries are removed for replacement. It is recommended to make note of the data stored in memory prior to changing batteries. -
Page 13: Setting The Clock
SETTING THE CLOCK Initial state. (When you load the batteries in the unit for the fi rst time, carry out the reset procedure.) * Date/hour/alarm setting when the batteries are fi rst loaded into the unit. Data and time: 12:00 am, January 1, 2007 Alarm: 12:00 am, alarm is in OFF state Date and time correcting procedure... - Page 14 SETTING THE CLOCK Correcting the “minute” of an alarm time • Press “MODE” switch for one second or more to place the unit in the alarm-time minute correction state. • Press “SET” switch to increase the minute of the alarm time in increments of one minute.
- Page 15 SETTING THE CLOCK Correcting the “hour” of the current time • After the completion of the current-time minute correction as described above, press “MODE” switch to place the unit in the current-time hour correction state. • Press “SET” switch to increase the hour of the current time in increments of one hour.
- Page 16 SETTING THE CLOCK Changeover of the “time system” • After the completion of the day-of-the-month correction as described above, press “MODE” switch to place the unit in the time system selection state. • Every time “SET” switch is pressed, the 12-hour system (12H) and (24H) will be changed over.
-
Page 17: Measuring Your Blood Pressure
MEASURING YOUR BLOOD PRESSURE ATTACHING THE ARM CUFF Unroll the arm cuff and thread the end through the metal hoop so that the side with the Velcro patch is on the outside. Metal hoop Put the arm cuff around your arm so that the blue marker comes to the palm side. - Page 18 MEASURING YOUR BLOOD PRESSURE Pull the end of the arm cuff outwards so that the cuff is snug around your arm and then secure the end to the Velcro. Place your arm on a table or the like so that the center of the cuff comes to the height of your heart.
-
Page 19: Tips For Obtaining Accurate Measurements
TIPS FOR OBTAINING ACCURATE MEASUREMENTS Your blood pressure varies according to your posture, the time of day and a range of other factors. Ideally, you should measure your blood pressure in the same posture at the same time every day. ■... -
Page 20: Start Measurement
MEASURING YOUR BLOOD PRESSURE Plug the air hose connector into the main unit. • Plug the air hose connector fi rmly into the air hose socket on the main unit as illustrated. Air hose socket Start measurement. • Press the "START/STOP" switch. •... - Page 21 MEASURING YOUR BLOOD PRESSURE • The Blood pressure monitor automatically carries out pressurization until the pressure that is best suited to the blood pressure measurement is reached. • When the unit determines that an adequate pressure is not obtained, the unit starts pressurization again. •...
- Page 22 MEASURING YOUR BLOOD PRESSURE [Manual pressurization] • Keep “START/STOP” switch held pressed until the pressure value you want to stop pressurization is reached (approximately 40mmHg higher than the Systolic blood pressure). You can stop pressurization by the unit by releasing the switch at the aforementioned value is reached.
-
Page 23: Automatic Changeover Feature
AUTOMATIC CHANGEOVER FEATURE • Press “START/STOP” switch after the completion of blood pressure measurement to revert the display to the time display. If you do not press the switch and leave the unit, the “Automatic changeover feature” of the unit will work approximately three minutes later to automatically revert the display to the time indication. -
Page 24: How To Call Up The Data Stored In Memory
HOW TO CALL UP THE DATA STORED IN MEMORY • Press the “MEMORY” switch. • “A” that represents the average value appears on the upper left section of the display. Then, the average of the whole data stored in memory appears on the display. -
Page 25: How To Delete The Data Stored In Memory
HOW TO DELETE THE DATA STORED IN MEMORY • The data stored in memory can be deleted. • Press “MEMORY” switch to call up the data you want to delete to the display. Keep the switch held pressed for three seconds or more to delete the data. Then, the buzzer sounds to let you know the completion of deletion of the data. -
Page 26: Key To Display Icons
KEY TO DISPLAY ICONS Icon displayed Condition/Cause Corrective action Insuffi cient pressure. Repeat measurement again. Appears when the blood- Reapply cuff properly and pressure could not be measure again. measured accurately. The pressure is 281 mmHg If the pressure does not or higher. -
Page 27: About "Blood Pressure
ABOUT “BLOOD PRESSURE” What is blood pressure? The heart is a pump that circulates blood throughout your body. Blood is pumped from the heart at a constant pressure into arteries. This pressure is called the arterial blood pressure and represents, in general terms, your blood pressure. Blood pressure is indicated by several kinds of pressures, including the systolic pressure that occurs when the heart pumps blood and the diastolic pressure that occurs when blood returns to the heart. -
Page 28: Blood Pressure Q&A
BLOOD PRESSURE Q&A Why is the blood pressure measured at home different from that measured by the physician or at a hospital? Your blood pressure may vary due to exercise, the ambient temperature or your mental state. When you have a physician or nurse measure your blood pressure, the pressure value is likely to be 10 to 20 mmHg higher than usual due to anxiety and/or stress. -
Page 29: Before Requesting Repairs Or Testing
BEFORE REQUESTING REPAIRS OR TESTING Make sure to check the following before sending your blood pressure monitor away to be tested or repaired. Problem Checks Response Display stays blank when Check whether the batteries Replace all the batteries with you press the “START/ are dead. -
Page 30: Specifications
SPECIFICATIONS Model Number: CH-462E Measurement system: Oscillometric method Measurement Localization Upper Arm Cuff: soft cuff Arm circumference range: 20.0 to 32.0 cm Pressure 0 to 280 mmHg Measurement range: Pulse 40 to 180 pulse/min Pressure ±3 mmHg Accuracy: Pulse ±5% of reading Clock ±20 second/Month Pressure... - Page 31 CITIZEN is a registered trademark of Citizen Holdings Co., Japan. CITIZEN es una marca registrada de Citizen Holdings Co., Japón. Design and Specification are subject to change without notice.
