Section 1
1.1 Rear Panel Connections

1.2 Front Panel

2 DriveRack
Getting Started
Left/Mono
IEC Power Cord Receptacle
®
The DriveRack PA comes with a power supply that will accept voltages ranging from 100V-
120V at frequencies from 50Hz-60Hz. An IEC cord is included. EU version accepts 220V-240V
at frequencies from 50Hz-60Hz.
Outputs 1-6
The output section of the DriveRack
Inputs 1-2
The input section of the DriveRack
+4/-10dBv Switch
This switch changes the level from either +4 or -10dBv.
Ground Lift Switch
The ground lift switch lifts the pin 1 chassis ground of both input XLR connectors.
CROSSOVER/ALIGNMENT DELAY/GRAPHIC EQ/PARAMETRIC EQ/AUTO/EQ
RTA Input Jack
This balanced XLR input is used for the connection of an RTA microphone, which allows the
user to "Pink" and optimize the EQ settings of any room through the use of the Auto EQ in the
Wizard setup assistant.
RTA MIC Input Selector
Pressing the RTA MIC input button will engage the front panel RTA input XLR connector.
Data Wheel
The Data wheel of the DriveRack
grams, select parameters and edit parameter values.
® PA User Manual
DriveRack
®
PA offers six electronically balanced XLR connectors.
® PA offers two electronically balanced XLR connectors.
®
PA is used to scroll through the program menu, load pro-
®
PA
Left/Mono
®
®
®
