Instrument Cluster Functions
1. Tachometer
The white area of the scale shows the
permissible engine revolutions-per-
minute (rpm x 1000) for each gear
range. Before the tachometer reaches
the red area, ease up on the accelera-
tor to prevent engine damage.
2. Electronic Throttle Control
Indicator Light
This light will turn on briefly
as a self-check when the ig-
nition switch is turned ON.
This light informs you of a
problem with the Electronic Throttle
Control system. When a problem is
detected, the light will illuminate
while the engine is running. If the light
turns on while the engine is running,
safely bring the vehicle to a complete
stop as soon as possible, place the
shift lever in PARK, and cycle the igni-
tion key. The light should turn off. If
the light remains lit with the engine
running, your vehicle will usually be
drivable. Nonetheless, see your au-
thorized Chery dealer for service as
soon as possible.
3. Maintenance Indicator Light
Every 5,000 km this warning
light will illuminate as a re-
minder that the vehicle should
be returned to your autho-
rized Chery dealer for maintenance.
4. Cruise Indicator
This indicator shows when
the Cruise Control system is
turned ON.
5. Turn Signal Indicator Light
The left or right arrow will
flash in unison with the cor-
responding front and rear
turn signal lights when the
turn signal switch is operated. Refer to
"Lights" in Chapter 3 of this manual for
more information.
Chery Automobile Co., Ltd.
YOUR INSTRUMENT PANEL – 81
6. Speedometer
The Speedometer indicates vehicle
speed in kilometers per hour (km/h).
NOTE: Use the tires designated for
your vehicle. Otherwise the speedom-
eter will not indicate the correct vehicle
speed.
7. Front Fog Light Indicator Light
This light illuminates when
the front fog lights are ON.
8. Brake System Warning Light
This light monitors various
brake functions, including
brake fluid level and brake
application. If the light illu-
minates it may indicate that the brake
fluid level is low or that there is a
problem with the brake system. When
this light is on, you should check
whether the brake fluid level is too
low. If the brake fluid level is too low,
