Implementing IPSec Network Security on Cisco IOS XR Software
Configuration Examples for Implementing IPSec Network
Security for Locally Sourced and Destined Traffic
This section provides the following configuration examples:
•
•
•
Configuring a Static Profile and Attaching to a tunnel-ipsec Interface: Example
The following example shows a minimal IPSec configuration where a static crypto profile is created and
attached to a tunnel-ipsec interface.
An IPSec access list named sample1 defines which traffic to protect:
ipv4 access-list sample1 permit ip 10.0.0.0 0.0.0.255 10.2.2.0 0.0.0.255
A transform set defines how the traffic is protected. In this example, transform set myset1 uses Data
Encryption Standard (DES) encryption and Secure Hash Algorithm (SHA) for data packet
authentication:
crypto ipsec transform-set myset1
transform esp-des esp-sha
Another transform set example is myset2, which uses 3DES encryption and the Message Digest 5 (MD5)
(Hashed Message Authentication Code [HMAC] variant) algorithm for data packet authentication:
crypto ipsec transform-set myset2
transform esp-3des esp-md5-hmac
A crypto profile named toRemoteSite is created and joins the IPSec access list and transform set:
crypto ipsec profile toRemoteSite
The toRemoteSite crypto profile is then applied to a tunnel-ipsec interface:
interface tunnel-ipsec0
Configuring a Dynamic Profile and Attaching It to a tunnel-ipsec Interface:
Example
The following example shows a minimal IPSec configuration where a dynamic crypto profile is created
and attached to a tunnel-ipsec interface.
An IPSec access list named sample2 defines which traffic to protect:
ipv4 access-list sample2 permit ip 10.0.0.0 0.0.0.255 10.2.2.0 0.0.0.255
A transform set defines how the traffic is protected. In this example, transform set myset2 uses DES
encryption and SHA for data packet authentication:
OL-20382-01

Configuration Examples for Implementing IPSec Network Security for Locally Sourced and Destined Traffic

Configuring a Static Profile and Attaching to a tunnel-ipsec Interface: Example, page 101
Configuring a Dynamic Profile and Attaching It to a tunnel-ipsec Interface: Example, page 101
Configuring a Static Profile and Attaching to Transport: Example, page 102
match sample1 transform-set myset1
end
profile toRemoteSite
tunnel source 10.0.0.2
tunnel destination 10.0.0.5
Cisco IOS XR System Security Configuration Guide for the Cisco CRS-1 Router
SC-101
