Ryobi JM82K Operator's Manual

Biscuit joiner double insulated
Hide thumbs Also See for JM82K:
Table of Contents

Advertisement

Quick Links

Your biscuit joiner has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
BISCUIT JOINER
DOUBLE INSULATED
JM82

Advertisement

Table of Contents
loading

Related Manuals for Ryobi JM82K

Summary of Contents for Ryobi JM82K

  • Page 1 OPERATOR’S MANUAL BISCUIT JOINER DOUBLE INSULATED JM82 Your biscuit joiner has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator's manual before using this product.

  • Page 2: Table Of Contents

    The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES n Avoid accidental starting. Be sure switch is off WARNING: before plugging in. Carrying tools with your finger on the switch or plugging in tools that have the switch on Read and understand all instructions. Failure to follow invites accidents.

  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES SERVICE n When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section n Tool service must be performed only by qualified of this manual. Use of unauthorized parts or failure to repair personnel. Service or maintenance performed by follow Maintenance Instructions may create a risk of unqualified personnel may result in a risk of injury.

  • Page 5: Symbols

    SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpreta- tion of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz...
  • Page 6 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury.

  • Page 7: Electrical

    ELECTRICAL DOUBLE INSULATION EXTENSION CORDS Double insulation is a concept in safety in electric power When using a power tool at a considerable distance from tools, which eliminates the need for the usual three- a power source, be sure to use an extension cord that has wire grounded power cord.

  • Page 8: Features

    FEATURES PRODUCT SPECIFICATIONS No Load Speed ..........10,000/min. Fence Angle Adjustments ........0-135° Input .......120 V, 60 Hz, AC only, 6.0 Amps Depth of Cut ............0-9/16 in. Net Weight.............. 8.4 lbs. Cord Length ...............10 ft. Blade ................4 in. DUAL GRIP HANDLE SWITCH TRIGGER...

  • Page 9: Dust Collection

    FEATURES KNOW YOUR BISCUIT JOINER ANGLE SETTING SCALE See Figure 1. The adjustable fence on the biscuit joiner can be set at angles from 0° to 135°. Before attempting to use this product, familiarize yourself with all operating features and safety rules. DUAL GRIP HANDLE The dual grip handle offers a choice of two grip positions SWITCH TRIGGER...

  • Page 10: Assembly

    ASSEMBLY INSTALLING/REMOVING THE DUST BAG UNPACKING See Figure 2. This product requires assembly. The dust bag located on the rear of the biscuit joiner pro- n Carefully remove the tool and any accessories from the vides a dust collection system. Wood particles are drawn up box.

  • Page 11: Operation

    OPERATION When joining 1-1/2 in. thick materials, stack two biscuits, one WARNING: above the other. For example, use this method when joining 2 in. x 4 in. dressed lumber. When joining even thicker materi- Do not allow familiarity with tools to make you careless. als, use additional biscuits, stacked above each other.
  • Page 12 OPERATION DEPTH OF CUT The biscuit joiner can be adjusted to three standard cutting depths to accommodate three standard size biscuits — #0, #10, and #20. Adjustments are made by engaging slots on the depth adjustment knob with tabs on the rear base as- sembly.
  • Page 13 OPERATION FENCE HEIGHT The adjustable fence on the biscuit joiner can be moved HEIGHT SETTING INDICATOR SCALE up or down to adjust the position of the blade in relation to POINT the top of the workpiece. A scale on each side of the fence indicates the height of the fence from the center of the blade.
  • Page 14 OPERATION MAKING EDGE-TO-EDGE JOINTS CENTERLINE See Figures 9 - 10. MARKS Edge-to-edge joinery is one of the most basic and easily- constructed joints. n Unplug the biscuit joiner. n Prepare the workpieces by laying them side by side on a workbench in the order in which they will be as- sembled.
  • Page 15 OPERATION BUTT JOINTS BUTT JOINTS A butt joint is made by mating the end grain of one board with the edge grain of another. The bonding of glue on this type of surface is poor. However, by using biscuits you can create a strong joint that gives a mortise-and-tenon effect.
  • Page 16 OPERATION T- JOINTS T-JOINT See Figure 13. A T-joint is used when the end of a board is joined to the face CENTERLINE of another board as shown in figure 12. Attaching shelves to MARK(S) bookcases and inner support braces to frames are typical applications.
  • Page 17 OPERATION CUTTING VERTICAL BOARDS See Figures 16 - 17. HEIGHT LOCKING ADJUSTMENT n Unplug the biscuit joiner. KNOB KNOB n Loosen the locking knob and set the fence angle at 0°. n Set the fence height at the desired dimension on the scale by rotating the height adjustment knob.
  • Page 18 OPERATION MITER JOINTS See Figures 18 - 21. There are two types of miter joints that can be made using biscuits: flat miters and edge miters. Flat miters are used BISCUIT when making picture frames. Edge miters are used when SLOT making boxes or things where you don’t want to show the end grain of the wood.
  • Page 19 OPERATION MAKING EDGE MITER JOINTS CUTTING EDGE MITER SLOT See Figures 19 - 21. FROM LONG SIDE OF WORKPIECE n Unplug the biscuit joiner. n Place the pieces of wood to be joined on a level work- bench. n Mark the centerline of the joint on each board. n When making edge miter joints with workpieces that have different thicknesses, clamp the pieces securely to a workbench with the long sides up.

  • Page 20: Adjustments

    REPLACING THE BLADE WARNING: See Figures 22 - 24. When servicing, use only identical Ryobi replacement After extended use, the blade on your biscuit joiner may parts. Use of any other parts may create a hazard or become dull and need replacing. If you accidentally hit a nail cause product damage.
  • Page 21 MAINTENANCE n Place a screwdriver in the hole provided in the bearing plate. NON-CUTTING TOOTH BEHIND n Place one of the non-cutting teeth located behind each SCREWDRIVER CARBIDE-TIPPED carbide-tipped cutting tooth against the screwdriver or CUTTING TOOTH pin and lock the blade to prevent it from rotating. DO NOT lock the blade against one of the cutting teeth.
  • Page 22 MAINTENANCE CLEANING THE BASE ASSEMBLY AND DUST SHOWN WITHOUT DUST BAG PATH SCREW(S) See Figures 25 - 27. SHOE After extended use, wood particles and resin may build up inside the base assembly of your biscuit joiner and clog the path for wood particles going into dust bag.
  • Page 23 MAINTENANCE n Using a screwdriver, remove the two screws that connect the front and rear base assemblies. n Carefully separate the front base assembly from the rear base assembly. Remove the front base assembly. NOTE: These pieces are tightly joined. It may be helpful to use a mallet to lightly tap the area where the assemblies meet.

  • Page 24: Accessories

    ACCESSORIES The following recommended accessories are currently available at retail stores: n Biscuits 100 pieces ..............................Size 0 n Biscuits 100 pieces ............................... Size 10 n Biscuits 100 pieces ............................... Size 20 n Biscuit Assortment ..........................400 pieces total Size 0................................100 pieces Size 10................................100 pieces Size 20................................200 pieces WARNING:...
  • Page 25 NOTES...

  • Page 26: Parts Ordering / Service

    When ordering repair parts, always give the following information: JM82 • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi Limited used under license. ® ONE WORLD TECHNOLOGIES, INC. 1428 Pearman Dairy Road, Anderson, SC 29625 Phone 1-800-525-2579 www.ryobitools.com...
