16 C 1: O
HAPTER VERVIEW
Interface Attributes
Table 15 Router 3016 LEDs (continued)
LED Description
T1-ACT Off means that no data is being sent or received through the port.
Green means that data is being sent and received through the port.
AUX Off means that no data is being sent or received through the AUX
port.
Green means that the link is connected.
Flashing green means that data is being sent or received over the AUX
port.
SYSTEM Flashing green means that the system is working properly.
On or off means that the system is not working properly
The Router 3016 provides a console port, an AUX port, a 10/100M Ethernet
interface, and a CT1/PRI port.
Console Port
Table 16 lists attributes of the console port.
Table 16 Attributes of the Console Port
Attribute Description
Connector RJ45
Interface standard Asynchronous EIA/TIA-232
Baud rate 9600 to 115200bps
Defaults to 9600bps
Services Connects with ASCII terminal
Connects with serial interfaces of the local PCs and runs the terminal
emulation program on the PCs
Command line interface
AUX Port
Table 17 lists attributes of the AUX port.
Table 17 Attributes of the AUX Port
Attribute Description
Connector RJ45
Interface standard Asynchronous EIA/TIA-232
Baud rate 300 to 115200bps
Services Modem dial-up
Backup
Protocols PPP (Point to Point Protocol)
SLIP (Serial Line Internet Protocol)
MP (Multilink PPP)
