Alpine KTX-TCM8-S Installation Manual

Mobile Media Solutions
Perfect Fit 2012-up Toyota Tacoma {Excluding
models with
J
BL}
Toyota Trim Panel x 1
(Panel 731 5)
• • (I
.--·-!
.
~
....... . .
-.:
.. :::-
.....
• /
.- ·
-.
T
'l,, ,
.
.,,,_.,._,
Left Bracket x 1
(Panel 7318)
KTX-TCMB-S
Power Harness x 1
Right Bracket x 1
(Panel 7317)
{;~ ~
;1 · = = ===- - -1;
I• 11
r~:;:~
1
1
!
[~~~~-=:
_ _ __
_li
·- - ·-··- --·- -r,::·:----·-·-
. . . r .•
KCX-SWCTY
Steering Wheel Interface
Module x 1
Screws x 4
Introduction
This KTX-TCM8-S Perfect Fit installation kit is for Select 2012+ Toyota Tacoma vehicles. Included
are all the parts needed to install your Alpine INE-Z928HD Audio Video Navigation system in
Select 2012+ Toyota Tacoma vehicles. KTX-TCM8-S Perfect Fit installation kit also includes an
interface module that allows steering wheel remote control of the Alpine system. Refer to the
individual instruction sections of this manual to remove your vehicle's factory radio and assemble
the kit.
Caution! Disconnect your vehicle's negative battery terminal before the installation to
help prevent electrical damage. We recommend the use of a digital multimeter to check
vehicle wiring. Do not use a test light! A test light or grounded wire probe can cause
damage to the vehicle's computer and/or diagnostic systems. Avoid all factory airbag
wiring. Airbags can accidentally deploy causing serious injury or even death.
Notes:
• See your vehicle's instructions for any special tools your installation might require.
• Read all instructions accompanying your car stereo for proper wiring and mounting
instructions.
