Alpine KTX-GM7-O Installation Manual

Mobile Media Solutions
Perfect Fit For Select 2006-up GM Vehicles
Installation Manual
KTX-GM7-0
0
0
GM Trim Panel x 1
(Panel 7229)
Power Harness x 1 On-Star/Steering Wheel
Interface Module x 1
Left Bracket x 1
{Panel 7231)
Right Bracket x 1
(Panel 7230)
GM Antenna
Adapter
Screws x 4
Introduction
This KTX-GM7-0 Perfect Fit installation kit is for Select 2006-up GM vehicles with or without the
Bose audio system. Included are all the parts needed to install your Alpine INA-NAV-1 0, INA-
NAV-20, INA-W900, INA-W900BT, or INA-W910 Audio Video Navigation system in Select 2006-up
GM vehicles. KTX-GM7-0 Perfect Fit installation kit also includes an interface module that allows
steering wheel remote control of the Alpine system. Refer to the individual instruction sections of
this manual to remove your vehicle's factory radio and assemble the kit.
Caution! Disconnect your vehicle's negative battery terminal before the installation to
help prevent electrical damage. We recommend the use of a digital multimeter to check
vehicle wiring. Do not use a test light! A test light or grounded wire probe can cause
damage to the vehicle's computer and/or diagnostic systems. Avoid all factory airbag
wiring. Airbags can accidentally deploy causing serious injury or even death.
Notes:
• See your vehicle's instructions for any special tools your installation might require.
• Read all instructions accompanying your car stereo for proper wiring and mounting
instructions.
