Alpine KTX-CMO Installation Manual

Vehicle Feature Settings Continued
Vehicle Feature Details
• Climate And Air Quality
Heated Seats: On or Off when vehicle is remote started
• Collision/Detection Systems
Park Assist features: Enable or Disable the vehicle's ultrasonic bumper object sensors (Depends on
vehicle options/equipment)
• Lighting
Exit Lighting: Set exterior lights delay when exiting vehicle at night
Vehicle Locator Lights: Set exterior lights ON or OFF when unlocking/approaching at night
• Power Door Locks
Unlocked Door Anti Lockout: Prevents vehicle locking if Driver door is open (Helps to prevent keys from
being locked inside).
Auto Door Unlock: Vehicle unlocks when Shifted into Park (Auto trans) or when Key is removed
(Manual Trans)
Delayed Door Lock: Delays door locking
• Remote Lock/Unlock/Start
Unlock Feedback (Lights): Enable or Disable vehicle's light Flash when Unlocking vehicle with Remote
Locking Feedback: Select the type of audible/visual Lock indicator when Locking vehicle
Remote - Lights Flash, Lights and Horn blip, or Horn blip only
Door Unlock Options: Selectable unlocking when using remote: Driver's door first or Both doors at once.
Remote Vehicle Starting: Enable or Disable Remote Vehicle Starting
• Aftermarket Radio Type (Steering Wheel Control Output)
Select type of Aftermarket Radio for steering wheel interface configuration (Pioneer, Sony, Alpine,
Kenwood, Clarion, JVC)
• Return to Factory Settings
Restores all customized settings to Factory default: Yes or No
How To Change Feature Settings
1. Press the "SET" button to access
the Configuration/Settings Menu
(see page 4, Fig. 1, #B)
2. Touch the "CAR" button on the TFT
screen (page 8, Fig. 3, #2) to bring
up the car Feature list.
3. Touch the name of the Feature you
would like to access/change the
settings (page 7, Fig. 4 #2). Note:
you may need to scroll down to
view all options.
4. Touch the option valUe you wish to
change and the selected value will
turn to GREEN or RED color text.
5. Touch the Back button (Fig. 5, f1,
above) to go back one level or view
other features.
Liability Disclaimer
Due to changes in design and manufacturing that may occur with your specific vehicle, it is important that
you do not rely solely on vehicle information contained in this installation manual, such as dash disassem-
bly, wire harness, and codes. Such information should be confirmed with the vehicle manufacturer. Alpine
Electronics, Inc. and its affiliated companies is not responsible for damage that may occur to you or your
automobile during the installation of the Perfect Fit Kit.
If you have any further questions, feel free to contact Alpine Tech Support at 1-800-NAV-HELP.
ALPINE ELECTRONICS OF AMERICA, INC., 19145 Gramercy Place, Torrance, CA 90501, U.S.A
ALPINE ELECTRONICS OF CANADA, INC., 777 Supertest Road, Toronto, Ontario M3J 2M9, Canada
Do not send products to these addresses.
Call the toll free number or visit the website to locate a service center.
<
1
Remote Start Auto Heated Seats
2
Figure 5
Vehicle Feature Screen
Layout
8
with the
Climate and Air Quality
1. Back Button
2. Vehicle Feature Value
3. Selected Vehicle Feature
3
