Intel Desktop Board D865PERC/D865PESO Technical Product Specification

1.2 Overview

1.2.1 Feature Summary

Table 2 summarizes the major features of the Desktop Boards D865PERC and D865PESO.
Table 2.

Feature Summary

Form Factor
Processor
Memory
Chipset
Video
Audio
I/O Control
USB
Peripheral
Interfaces
LAN Support
12
D865PERC: ATX (11.60 inches by 9.60 inches [294.64 millimeters by
243.84 millimeters])
D865PESO: microATX (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
• Support for an Intel
®
Pentium
400/533/800 MHz system bus
• Support for an Intel
®
Celeron
400 MHz system bus
• Four 184-pin DDR SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for DDR 400, DDR 333, and DDR 266
• Support for up to 4 GB of system memory
Intel ® 865PE Chipset, consisting of:
• Intel
®
82865PE Memory Controller Hub (MCH)
• Intel
®
82801EB I/O Controller Hub (ICH5)
• 4 Mbit Firmware Hub (FWH)
Universal 0.8 V / 1.5 V AGP 3.0 connector (with integrated retention mechanism)
supporting 1x, 4x, and 8x AGP cards or an AGP Digital Display (ADD) card
Flex 6 audio subsystem using the Analog Devices AD1985 codec
LPC Bus I/O controller
Support for USB 2.0 devices
• Eight USB ports
• One serial port
• One parallel port
• Two Serial ATA interfaces
• Two Parallel ATA IDE interfaces with UDMA 33, ATA-66/100 support
• One diskette drive interface
• PS/2* keyboard and mouse ports
The board provides one of the following:
• Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel
Platform LAN Connect (PLC) device
• 10/100 Mbits/sec LAN subsystem using the Intel
Connect (PLC) device
®
4 processor in an mPGA478 socket with a
®
processor in an mPGA478 socket with a
®
82562EZ Platform LAN
®
82547EI
continued
