Chapter 9

Step 10: Tighten down the rack mounting screws.

Once all 12 Torx screws (6 in the front and 6 in the rear) have been finger-
tightened, use a T25 Torx driver to tighten them down in two passes while
applying downward pressure on the chassis:
On the first pass, snug the screws 90 to 180 .
On the second pass, tighten them all the way down.
NOTE Apply downward pressure on the LPr chassis as you tighten
the screws to ensure that it seats within its two EIA spaces;
otherwise, you may find that it sits a little high and gets into
the EIA space above it.

Continue with the Installation Process

After you install the HP NetServer in the rack, refer to Chapter 1 to continue with
the process of installing and configuring your HP rack system.

Removing the NetServer from the Rack

You must remove the NetServer LPr entirely from the rack to access internal
components.
NOTE To remove the LPr from the rack, you must disconnect signal
and power connectors from the NetServer's rear panel. If
necessary, mark the cables clearly as you remove them to
support reassembly.
Follow these steps:
1. Log off all users. Back up files. Follow instructions in your network
operating system (NOS) documentation to gracefully shut down all
networking software and applications.
2. Press the power switch on the HP NetServer's control panel when
prompted by the operating system.
74
Mounting the Server in the Rack
