Chapter 4
The Cancel button cancels the entire configuration, including what was
set up under the Disk Arrays, Logical Drives, and LUN Mapping tabs.
NOTE HP requires LUN 0 on each active port, however, the order and
value of LUNs on each port is flexible. See Figures 4-45 and
4-46 for examples.
Figure 4-46. LUN Mapping in Dual Active Mode
6. Click Apply when ready to accept the entire RAID Controller
configuration you've specified across all Manual Configuration tabs.
There will be a confirmation message followed by a prompt message:
Do You Want To Reset?
7. If you wish to reset the selections, press YES to reset the controller
configuration.
Reset will take a couple of minutes to update the FCArray Controller(s)
with the new configuration settings.
84
Configuration
