Chapter 3
(64-Bit Slots)
PCI Slot P1
PCI Slot P2
PCI Slot P3
PCI Slot P4
PCI Slot P5
(5 volt, blue)
NOTE Refer to the HP web site at
slot recommendations for a particular accessory board type.
7. Remove the slot cover latch:
a. Lift up on tab of slot cover latch.
b. Raise the slot cover latch up from the slot covers.
c. Remove it from the chassis and keep it for reassembly. See
You may need to lift the slot cover latch out of its retainer before lifting it out of the chassis.
Figure 3-19. Accessory Board Slots
http://www.hp.com/
Installing and Configuring
for specific
Figure 3-20 and Figure 3-21.
38
