3 Playing Along With the Click
8
Save an Original Click Set
After creating your own original Click Set, save it in the
DTX500's memory using the Store Operation described
below.
NOTICE
• Any changes made to the data will be lost if another Click
Set is selected before carrying out the store operation. If
you want to keep settings or changes, make sure to carry
out the Store Operation.
8-1. Press the [SAVE/ENTER] button. The following dis-
play will appear.
CLK~save~to~1
:[User~~]
Click Set Name
8-2. Rotate the jog dial to select the destination memory
number (1 to 30) to which you want to store the Click
Set.
8-3. If you want to change the Click Set name, press the
< >
[ ]/[ ] buttons to move the flashing cursor to the
character you want to edit, then rotate the jog dial to
select the desired character. A Click Set name can con-
tain a maximum of six characters, and these can be
selected from the following list.
space
!"#$%&'()*+,-./0123456789:;<=>?@
ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`
abcdefghijklmnopqrstuvwxyz{|}≥≤
8-4. Press the [SAVE/ENTER] button again. A prompt
appears asking you to confirm the Store operation.
CLK~save~to~1
~Are~you~sure~?
8-5. Press the [SAVE/ENTER] button to actually execute
the Store operation.
* To cancel the Store operation, press any button
except for the [SAVE/ENTER] and [SHIFT] buttons.
(When "Are you sure?" appears in the display, the jog
dial will also cancel the operation.)
The following display appears after the Store opera-
tion is complete.
~~~Completed!
18
DTX500 Owner's Manual
Store Destination
NOTE
• You can use the Factory Set operation to reset the click sets 1
through 30 to their original factory condition. However,
please proceed with caution because carrying out this opera-
tion will rewrite the DTX500's entire contents (all Click Sets,
User Trigger Setups 8–11, User Drum Kits 51–70, User
Songs 64–83, Utility settings) with the data that was set in the
unit's memory when it was shipped from the factory (p. 33).

Click Out Select

The DTX500 lets you select from which output jack the
signal of the click (metronome) is sent. Click output and
performance output can be routed to separate outputs.
Operation
1. First, press the [SHIFT] + [SAVE/ENTER] buttons to
call up the Utility display.
UTIL1~Hi-hat
HHofs=~~0~T=~~5‚
2. Next, press the [>] button twice to call up the follow-
ing display.
UTIL2~Click
"OutSel=mix~~~~‚
3. Rotate the jog dial to select the output from the out-
puts listed below.
mix
This is the standard output setting. The click sig-
nal is output from both the OUTPUT L and R
jacks.
clickL
The click signal is output from the OUTPUT L
jack only. All drum performance and song play-
back are output in mono via the OUTPUT R jack.
clickR
The click signal is output from the OUTPUT R
jack only. All drum performance and song play-
back are output in mono via the OUTPUT L jack.
* The PHONES jack outputs the same signal as the OUT-
PUT jacks. The settings in this section would then also be
applied to the PHONES jack's stereo L and R.
