Intel ® D2700 Graphics Subsystem - Intel BOXD2700DC Specification

1.3.1 Intel
®
1.3.1.1 Intel
Controller (Intel
®
The Intel GMA 3650 graphics controller features the following:
• 640 MHz core frequency
• High quality texture engine
⎯ DX9.3* and OpenGL* 3.0 compliant
⎯ Hardware Pixel Shader 4.1
⎯ Vertex Shader Model 4.1
• Video
⎯ Blu-Ray 2.0
⎯ H.264 & VC1 hardware decoder
⎯ PAVP 1.1c
⎯ HDCP 1.3
• Display
⎯ Supports HDMI and DVI displays up to 1920 x 1200 at 60 Hz refresh (WUXGA)
⎯ Dual independent display support
For information about
Obtaining graphics software and utilities
1.3.1.2 High Definition Multimedia Interface* (HDMI*)
The HDMI port supports standard, enhanced, or high definition video, plus multi-
channel digital audio on a single cable. . The maximum supported resolution is 1920 x
1200 (WUXGA). The HDMI port is compliant with the HDMI 1.3a specification
The HDMI port is enabled for POST whenever a monitor is attached
®
D2700 Graphics Subsystem
Graphics Media Accelerator 3650 Graphics
®
GMA)
Product Description
Refer to
Section 1.2, page 16
17
