Cisco MDS 9000 Switch Management
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Table 2-1
Management Protocol
Telnet/SSH
FTP/SFTP/TFTP, SCP
SNMPv1, v2c, and v3
HTTP/HTTPS
XML/CIM over HTTP/HTTPS
ANSI T11 FC-GS-3

Storage Management Solutions Architecture

Management services required for the storage environment can be divided into five layers, with the
bottom layer being closest to the physical storage network equipment, and the top layer managing the
interface between applications and storage resources.
Cisco MDS 9000 Family Fabric Manager Configuration Guide
2-16
Supported Management Protocols
Chapter 2 Installing Cisco MDS NX-OS and Fabric Manager
Purpose
Provides remote access to the CLI for a Cisco
MDS 9000 switch.
Copies configuration and software images
between devices.
Includes over 80 distinct Management
Information Bases (MIBs). Cisco MDS 9000
Family switches support SNMP version 1, 2, and
3 and RMON V1 and V2. RMON provides
advanced alarm and event management, including
setting thresholds and sending notifications based
on changes in device or network behavior.
By default, the Cisco Fabric Manager
communicates with Cisco MDS 9000 Family
switches using SNMPv3, which provides secure
authentication using encrypted user names and
passwords. SNMPv3 also provides the option to
encrypt all management traffic.
Includes HTTP and HTTPS for web browsers to
communicate with Fabric Manager Web Services
and for the distribution and installation of the
Cisco Fabric Manager software. It is not used for
communication between the Cisco Fabric
Manager Server and Cisco MDS 9000 Family
switches.
Includes CIM server support for designing storage
area network management applications to run on
Cisco SAN-OS and NX-OS.
Provides Fibre Channel-Generic Services
(FC-GS-3) in the defining management servers in
the Fabric Configuration Server (FCS). Fabric
Manager uses the information provided by FCS on
top of the information contained in the Name
Server database and in the Fibre Channel Shortest
Path First (FSPF) topology database to build a
detailed topology view and collect information for
all the devices building the fabric.
OL-17256-03, Cisco MDS NX-OS Release 4.x
