Inventory

S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Inventory
The Inventory tab shows an inventory of the selected SAN, fabric, or switch. You can export this
information to an ASCII file in comma-separated value format that can be read by applications such as
Microsoft Excel. You can set the number of rows and columns per page.
The Inventory tab contains the following subtabs:
•
•
•
•
•
•
•
•
•

Viewing Summary Inventory Information

To view a summary of VSANs, switches, ISLs, ports, and end devices using Fabric Manager Web Client,
follow these steps:
Step 1 Click the Inventory tab, and then click Summary.
You see the Summary tab window as shown in
Figure 7-21
Do one of the following:
Step 2
Cisco MDS 9000 Family Fabric Manager Configuration Guide
7-28
VSANs—Shows details about VSANs.
Switches—Shows details about switches.
Licenses—Shows details about the licenses in use in the fabric.
Modules—Shows details for MDS switching and services modules, fans, and power supplies.
End Devices—Shows the host and storage ports.
ISLs—Shows the Inter-Switch Links.
NPV Links—Shows the links betweek NPV devices and ports.
Zones—Shows the active zone members (including those in inter-VSAN zones).
Summary—Shows VSANs, switches, ISLs, ports, and end devices.
Summary Tab
Chapter 7
Figure 7-21.
OL-17256-03, Cisco MDS NX-OS Release 4.x
Fabric Manager Web Client
