Removing a Drive from the Drive Bay
2-24 Hardware Upgrades
1.
Shut down the operating system properly, then turn off the
computer, disconnect the power cord from the power outlet, and
remove the computer access panel.
2.
Remove the front bezel.
3.
Disconnect the drive power and signal cables and, if it is a
CD-ROM, DVD-ROM, or PD-CD drive, disconnect the audio
connector.
4.
Press drivelock mechanisms (
drive bay.
Drivelock
Secures the 5.25-Inch Drives in the Desktop and
Drives in the Minitower (Shown from the Rear of the Chassis)
or
) to unlock the drive in the
Secures All
