v If the system hangs on a progress code, follow the suggested actions in the order in which they are listed
in the Action column until the problem is resolved.
v See Chapter 3, "Parts listing, Types 7988 and 8844," on page 137 to determine which components are
CRUs and which components are FRUs.
v If an action step is preceded by "(Trained service technician only)," that step must be performed only by a
trained service technician.
Progress code
C400E215
C400E216
C400E217
C400E218
C400E219
C400E21A
C400E21B
C400E21C
C400E21D
C400E21E
C400E220
18
BladeCenter JS21 Types 7988 and 8844: Problem Determination and Service Guide
Description
Pattern 2 memory test
Clear memory
Initialize LLFW global data structure
Copying the set of flash RAM to memory 1. Go to "Checkout procedure" on page 106.
Saving the DIMM SPDs and the CPU
status and presence
Executing code from memory
Load PFW into memory
Executing HT initialization
Executing PCI initialization
Execute I/O APIC test
Read 4K system VPD eeprom Data
Action
1. Verify that DIMMs are correctly installed and
seated, then restart server.
2. Start server from PERM image and recover
TEMP image.
3. Replace the system-board and chassis
assembly.
1. Verify that DIMMs are correctly installed and
seated, then restart server.
2. Start server from PERM image and recover
TEMP image.
3. Replace the system-board and chassis
assembly.
1. Go to "Checkout procedure" on page 106.
2. Replace the system-board and chassis
assembly.
2. Replace the system-board and chassis
assembly.
1. Go to "Checkout procedure" on page 106.
2. Replace the system-board and chassis
assembly.
1. Go to "Checkout procedure" on page 106.
2. Replace the system-board and chassis
assembly.
1. Go to "Checkout procedure" on page 106.
2. Replace the system-board and chassis
assembly.
1. Go to "Checkout procedure" on page 106.
2. Replace the system-board and chassis
assembly.
1. Go to "Checkout procedure" on page 106.
2. Replace the system-board and chassis
assembly.
1. Go to "Checkout procedure" on page 106.
2. Replace the system-board and chassis
assembly.
1. Go to "Checkout procedure" on page 106.
2. Replace the system-board and chassis
assembly.
