Bandwidth Apply – Specifies the bandwidth you get from your ISP. If you are not clear about
that, please contact with your ISP for help.
IP Range – Specifies the IP range of this entry.
Mode – There are 2 types of mode: Minimum Bandwidth Guarantee and Maximum
Bandwidth Limit.
Bandwidth – Specifies the bandwidth you want to supply to this entry.
Description – Description of this entry.
Enable – Enable this entry. This entry won't be effective unless you check the Enable box.
Click the Delete button to delete single entry.
Click the Delete All button to delete all entries.
Click the Save button to save all configuration.
For example, we assume that PC A, B, C are sharing the Internet with 2Mbps bandwidth through
one router. PC A is often for VoIP or online games, to guarantee its better performance without
interference from PC B and C, you can specify the minimum bandwidth for PC A such as
100Kbps.
Note:
1. The conversion relation of bandwidth: 1 Mbps = 1000Kbps.
2. Please choose the Network Connection Type and set the bandwidth according to your
Network. If you are not clear about that, please contact with your ISP for help.
3. IP address range for different entries could not have intersection with each other.
4. After the configuration, click the Save button for the change to take effect.
4.11 IP & MAC Binding Setting
Figure 4-46 the IP & MAC Binding menu
58
