AC power socket: Please use the power adapter which is supplied with the TL-WR541G
LAN 1,2,3,4:
WAN:
Reset button:
There are two ways to reset the router's factory defaults:
1) Use the Factory Defaults function on System Tools -> Factory Defaults page in the
router's Web-based Utility.
2) Use the Factory Default Reset button: With the router powered on, use a pin to press and
hold the Reset button(about 5 seconds) until the SYS LED becomes quick-flash from
slow-flash. And then release the button and wait the router to reboot to its factory default
settings.
Note: Ensure the router is powered on before it restarts completely.
Wireless antenna
54Mbps Wireless Router only, the use of a different adapter may result
in product damage.
Four 10/100Mbps RJ45 LAN ports for connecting the router to the local
PC(s)
This WAN port is where you will connect the cable/DSL Modem, or
Ethernet
Figure 1-2 Rear Panel sketch
5
