HP Jetdirect IPsec/Firewall Wizard

Use the IPsec/Firewall wizard to create one or more rules that will be applied to IP traffic. Click Add
Rules to start the IPsec/Firewall wizard.
The wizard guides you through the configuration of up to ten rules, each rule specifying the host
addresses, services, and the action to take for those addresses and services. Depending on whether
IPsec is supported by the print server and device, the following actions are available:
● Allow traffic. (If IPsec/Firewall is supported, allow IP traffic that is not protected by the IPsec/Firewall
policy.)
●
Drop traffic. Do not process (discard) the specified IP traffic.
●
Require traffic to be protected with the IPsec/Firewall policy. For this action, you will be prompted
to configure an IPsec template, that is, the IPsec authentication/encryption settings to be applied
to the specified IP traffic.
See the illustration below.
HP Jetdirect
IPsec/Firewall Policy
IPsec/Firewall Rules
Figure 5-3 Use the IPsec Wizard to configure rules

Limitations to Rules, Templates and Services

Limitations to rules, templates, and services are summarized in the following table.
Table 5-2 Limitations to Rules, Templates and Services
Item
The maximum number of rules that can be configured
The maximum number of Address Templates that can be used.
ENWW
Use the IPsec/Firewall Wizard
to Configure Each Rule
Rule 1
Step 1, select:
Addresses1
Step 1, select:
Addresses2
Rule 2
Step 2, select:
Services1
Step 2, select:
Services2
Limit
10
8
HP Jetdirect IPsec/Firewall Wizard 101
Step 3, select:
Allow, Drop, or
Protect with IPsec1
Step 3, select:
Allow, Drop, or
Protect with IPsec2
