Table 5-2 Limitations to Rules, Templates and Services (continued)
Item
Note the following:
●
The All IP Addresses template results in two (2) address template rules: one for all IPv4
addresses, and another for all IPv6 addresses.
●
The All non link local IPv6 template results in four (4) address template rules.
● :: to FE7F:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF for both local and remote addresses
●
:: to FE7F:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF for local addresses
FE81:: to FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF for remote addresses
●
FE81:: to FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF for local addresses,
:: to FE7F:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF for remote addresses
● FE81:: to FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF:FFFF for both local and remote
addresses
●
The All Broadcast/Multicast Addresses template results in four (4) address template rules.
●
224.0.0.0 to 239.255.255.255 IPv4 local addresses and all IPv4 remote addresses
●
A single IPv4 local address, and all IPv4 remote addresses
●
255.255.255.255 local address, and all IPv4 remote addresses
●
FF00:: / 8 local IPv6 addresses, and all IPv6 remote addresses
NOTE:
address templates.
The maximum number of user-defined address templates that can be configured.
The maximum number of services that can be added to a user-defined service template.
NOTE:
all services supported by the print server.
The maximum number of services that can be added to the policy.
For example, if a user-defined service template consists of 64 services, then it is the only service
template that can be used.
The maximum number of service templates that can be used in the policy.
The maximum number of user-defined custom service templates that can be configured.
The maximum number of IPsec templates that can be used in the IPsec policy.
The maximum number of user-defined custom IPsec templates that can be configured.

Step 1: Specify Address Template

The available address templates for which a rule will apply are listed in the Address Templates field
by name. Select a predefined template, or click New to create a custom template using the Create
Address Template page, described below.
To view or delete a template in the list, select it and click View or Delete (you may not be able to delete
some predefined templates).
102 Chapter 5 IPsec/Firewall Configuration (V.36.xx)
If multiple rules for these predefined address templates are not desired, create custom
The predefined All Services template is not subject to this limitation and will include
Limit
8
64
64
10
10
5
5
