Jetdirect EIO Menus for Classic Control Panels

Classic control panels are provided on older devices that support HP Jetdirect EIO print servers only.
Classic control panels can typically display two lines of 16 characters each. You must use the available
device keys to display and select HP Jetdirect settings. Typically, an asterisk (*) is used to identify the
selected value.
Figure C-2
Table C-2 HP Jetdirect EIO Menu on Classic Control Panel
Menu Item
CFG NETWORK
TCP/IP
IPX/SPX
DLC/LLC
ATALK
CFG TCP/IP
178 Appendix C HP Jetdirect Control Panel Menus (V.36.xx)
Example of Classic Control Panel
Description
Selects whether or not you want to access the Jetdirect menu.
NO (default): Bypass the HP Jetdirect menu.
YES: Access the HP Jetdirect menu. You must change this to
the menu.
Identifies whether the protocol stack is enabled or disabled.
ON: The protocol is enabled.
OFF: The protocol is disabled.
NOTE:
only TCP/IP is enabled on HP Jetdirect 635n print servers.
Selects whether you want to access the TCP/IP menu and set TCP/IP protocol parameters.
NO (default): Bypass the TCP/IP menu items.
YES: Access the TCP/IP menu items.
● BOOTP=YES*
●
DHCP=YES*
If DHCP=YES*
following DHCP settings:
●
RELEASE: Choose
● RENEW: Choose
lease.
●
AUTO IP=YES*
The factory default setting depends on the print server model. For example,
enables IPv4 configuration by a BootP Server.
enables IPv4 configuration by a DHCP Server.
and the print server has a DHCP lease, you can choose to configure the
YES to release, or
YES to renew the current DHCP lease, or
will automatically assign a link-local IPv4 address in the form 169.254.x.x.
YES* each time you want to access
NO to save, the current DHCP lease.
NO to not renew the DHCP
