NETGEAR DGND3700v2 Installation Manual

NETGEAR DGND3700v2 Installation Manual

N600 wireless dual band gigabit adsl2+ modem router
Hide thumbs Also See for DGND3700v2:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Technical Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label
of your product and use it to register your product at
NETGEAR.com/register.
Registration is required before you can
use our telephone support service. Registration through our
website is strongly recommended.
Go to
support.netgear.com
for product updates and web support.
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
March 2012
N600 Wireless Dual Band Gigabit
ADSL2+ Modem Router DGND3700v2

Installation Guide

Package Contents

The box should contain the following items. If any items are
incorrect, missing, or damaged, contact your NETGEAR dealer.
ADSL
Phone
ADSL filter
Th
The ADSL filter provided
de
depends on the region.
N600 Wireless Modem Router
N600 Wireless Modem Router
Ethernet cable
Phone cable
Power adapter

Advertisement

Table of Contents
loading

Related Manuals for NETGEAR DGND3700v2

Summary of Contents for NETGEAR DGND3700v2

  • Page 1: Package Contents

    Thank you for selecting NETGEAR products. The box should contain the following items. If any items are incorrect, missing, or damaged, contact your NETGEAR dealer. After installing your device, locate the serial number on the label N600 Wireless Dual Band Gigabit...
  • Page 2 You can use this diagram to connect your modem router to ADSL (1a) or Cable/Fiber (1b), or you can follow the Declarations of Conformity instructions in this booklet. For complete DoC please visit the NETGEAR EU Declarations of Conformity website at: support.netgear.com/app/answers/detail/a_id/11621/. For GNU General Public License (GPL) related information, please visit support.netgear.com/app/answers/detail/a_id/2649.

  • Page 3: Table Of Contents

    Contents Before You Begin ........2 Install Your Modem Router .

  • Page 4: Before You Begin

    For example, you could say: I need my DSL service user name and password. Can you help Note: If your provider says they do not support NETGEAR devices, tell them you need only your DSL user name and...
  • Page 5 DSL Internet Service Provider Phone Number AT&T DSL (not AT&T U-Verse) 877-722-3755 AT&T/BellSouth DSL (not AT&T U-Verse) 888-321-2375 CenturyLink 800-809-1410 Covad DSL 888-642-6823 EarthLink 888-829-8466 Qwest 800-247-7285 SureWest 888-639-1611 TDS DSL Support 866-571-6662 US Family 800-300-4256 Verizon 800-567-6789 Windstream 877-901-4692...

  • Page 6: Install Your Modem Router

    Install Your Modem Router Note: Keep your modem router in a vertical position. To install your modem router:  Connect to the Internet with ADSL or Ethernet WAN. You can connect either directly to a DSL line or to a fiber/cable modem.
  • Page 7 Note: Use an ADSL microfilter for every phone line in the house if your modem router and telephone connect to the same phone line. Plugs into ADSL line b. Connect to Cable/Fiber (if connecting to a cable/fiber modem). Internet Cable/Fiber Modem Cable your computer.
  • Page 8 Power on your router. Internet Internet 2.4 GHz 2.4 GHz 2.4 GHz Wireless LED Wireless LED Wi l a. Connect the power adapter to the router, and plug the power adapter into an outlet. b. Wait until the 2.4 GHz Wireless LED turns solid green.
  • Page 9 After connecting to the Internet, check for firmware updates by selecting Advanced > Administration > Router Upgrade and following the on screen prompts. Click Logout and close your browser. You are now able to enjoy your Internet service with the NETGEAR DGND3700v2 N600 Wireless Modem Router.

  • Page 10: Preset Wireless Security

    WiFi Network Name (SSID) Network Key (Password) NETGEAR recommends that you do not change the preset WiFi network name (SSID) and network key (password). If you do change the settings, the security SSID and password on the bottom of the product no longer apply.

  • Page 11: Wireless Network Settings

    Wireless Network Settings Record the default preset wireless settings that are printed on the label in the spaces here for easy reference. 2.4 GHz WiFi network name (SSID): 2.4 GHz network key (password): 5 GHz WiFi network name (SSID): 5 GHz network key (password): If you change the default settings, record them here for easy reference, and then store this booklet in a safe place: 2.4 GHz WiFi network name (SSID):...

  • Page 12: Add Wireless Devices To The Network

    This utility scans for all wireless networks in your area. Look for the preset NETGEAR WiFi network name (SSID) and select it. The SSID is located on the product label on the bottom of the router.

  • Page 13: Access The N600 Router To Make Changes

    Repeat steps 1–3 to add other wireless devices. Access the N600 Router to Make Changes After you use NETGEAR Genie to set up the router, you can log in to the router to view its settings or make changes. ...
  • Page 14 See the User Manual for more information about the router screens. To change the password for the router user name:  Log in to the router. Select Advanced > Administration > Set Password to display the Set Password screen: Type your old password, and type the new password twice.

  • Page 15: Troubleshooting

    Troubleshooting If the browser does not display the web page: • Make sure that the computer is connected to one of the four LAN Ethernet ports, or wirelessly to the router. • Make sure that the router is fully up and running. Its WiFi LED should turn on.
  • Page 16 e. Turn your computer back on, and wait for the indicator lights to turn green. Open a web browser and try to access the Internet. If steps 1–3 do not resolve the problem: Reset your modem. To reset your DSL modem router, use a pin or paper clip to press in and hold the Reset button.

  • Page 17: Readyshare Access

    Note: If your USB device requires a power supply, you have to use it when connecting your USB device to a NETGEAR router or gateway. It might take up to 2 minutes before the USB drive is ready for sharing after it is connected to the router.
  • Page 18 The readyshareconnect.exe file (for Windows) is available to download here: www.netgear.com/readyshare...

  • Page 19: Usb Control Center

    The utility has to be installed on each computer on your network from which you want to control the device. You can download this utility at www.netgear.com/landing/en-us/readyshare.aspx. When you launch the USB Control Center utility, a screen similar to the following displays: This is the main screen, which shows a device icon, the description for this USB device, and its status.

  • Page 20: Control Center Configuration

    The following menu selections are available: • System. Exit the utility. • Tools. Access the Control Center Configuration to set up your shared USB device. See the following section, Control Center Configuration. • About. View details about the USB Control Center software. Control Center Configuration Select Tools >...

  • Page 21: Usb Printer

    Language. Select the display language for this utility. USB Printer The first time you use a printer, you need to click Connect. You might be asked to install the driver for this printer. After the driver is installed, the printer status changes to Available. Note: Some USB printers (for example: HP and Lexmark printer) request that you do not connect the USB cable until you are prompted...

  • Page 22: Scan With A Multifunction Printer

    prints. After the print job is done, the printer status returns to the Paused state. Scan with a Multifunction Printer You can use the scan feature of a multifunction printer. Make sure that the printer’s status shows as Available. Click the Network Scanner button. This activates the scanner window that is used to perform the scans.

  • Page 23: Other Features

    Trademarks NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to change without notice. Other brand and product names are registered trademarks or trademarks of their respective holders.
