Introduction of 601CF Motherboard

1-1 Feature of motherboard

The 601CF motherboard is design for use Intel's new generation Pentium processors,
which utilize the Socket 370 design and the memory size expandable to 1GB (using
256Mb technology). This motherboard integrated VGA, Audio, and PC Health
Function with Micro ATX form factor to support total solution for today's computer
market.
This motherboard using VIA Apollo PLE133 VT8601A and VT82C686B chipset,
whose 133MHz front side bus delivers a clear upgrade path to the future generation of
133MHz processors and PC-100/PC-133 SDRAM. The 601CF motherboard offers
ULTRA DMA 66/100 (ATA 100) to provide speedier HDD throughout that boosts
overall system performance.
The 601CF also has an integrated AC'97 2.1 CODEC on board which is fully
compatible with Sound Blaster Pro  that gives you the best sound quality and
compatibility. VIA VT8601A chipset also includes integrated 3D Graphic Acceleration to
provide a lower cost video display solution.
With USB control as well as capability of expanding to 4 USB connectors support four
USB devices, the 601CF meet future USB demand. Moreover, it has built-in hardware
monitor function to monitor and protect your computer.
This motherboard provides high performance & meets future specification demand. It
is really wise choice for your computer.

1-2 Specification
