2. In Archive, click Change and then specify the name of the archive.
3. In Backup, click Change and then select the backup from which you want to recover data.
4. In Data type, select Volumes.
5. In Items to recover, select the check box next to my_volgroup-my_logvol.
6. Under Where to recover, click Change, and then select the logical volume that you created in
Step 1. Click the chevron buttons to expand the list of disks.
7. Click OK to start the recovery.
For a complete list of commands and utilities that you can use in the bootable media environment,
see List of commands and utilities available in Linux-based bootable media (p. 261). For detailed
descriptions of the trueimagecmd and trueimagemnt utilities, see the Acronis Backup & Recovery 10
command line reference.
Mounting backup volumes
You may want to mount a volume stored in a disk backup, for example, to view some files in it before
starting the recovery.
To mount a backup volume
1. Use the --list command to list the volumes which are stored in the backup. For example:
trueimagecmd --list --filename:smb://server/backups/linux_machine.tib
The output will contain lines similar to the following:
Num Idx Partition Flags Start Size
---- --- --------- ----- ----- --------- ------
Disk 1:
Table
Disk 2:
Table
...
Dynamic & GPT Volumes:
DYN1 4 my_volgroup-my_logvol 12533760
You will need the volume's index, given in the Idx column, in the next step.
2. Use the --mount command, specifying the volume's index in the -i parameter. For example:
trueimagemnt --mount /mnt --filename smb://server/backups/linux_machine.tib -i
4
This command mounts the logical volume DYN1, whose index in the backup is 4, on the mount
point /mnt.
To unmount a backup volume

Use the --unmount command, specifying the volume's mount point as a parameter. For example:
trueimagemnt --unmount /mnt

6.10.6 Acronis PXE Server

Acronis PXE Server allows for booting machines to Acronis bootable components through the
network.
Network booting:

eliminates the need to have a technician onsite to install the bootable media into the system that
must be booted
266
Type
0 Table
0 Table
Ext2
