Choose one of the following:
 Now - to start the validation task right after its creation, that is, after clicking OK on the
Validation page.

Later - to start the one-time validation task, at the date and time you specify.
Specify the appropriate parameters as follows:

Date and time - the date and time when to start the task.
 The task will be started manually (do not schedule the task) - select this check box, if you
wish to start the task manually later.

On schedule - to schedule the task. To learn more about how to configure the scheduling
parameters, please see the Scheduling (p. 158) section.

6.5 Mounting an image

Mounting volumes from a disk backup (image) lets you access the volumes as though they were
physical disks. Multiple volumes contained in the same backup can be mounted within a single
mount operation. The mount operation is available when the console is connected to a managed
machine running either Windows or Linux.
Mounting volumes in the read/write mode enables you to modify the backup content, that is, save,
move, create, delete files or folders, and run executables consisting of one file.
Limitation: Mounting of volume backups stored on Acronis Backup & Recovery 10 Storage Node is not possible.
Usage scenarios:
 Sharing: mounted images can be easily shared to networked users.

"Band aid" database recovery solution: mount up an image that contains an SQL database from
a recently failed machine. This will give access to the database until the failed machine is
recovered.

Offline virus clean: if a machine is attacked, the administrator shuts it down, boots with bootable
media and creates an image. Then, the administrator mounts this image in read/write mode,
scans and cleans it with an antivirus program, and finally recovers the machine.

Error check: if recovery failed due to a disk error, mount the image in the read/write mode.
Then, check the mounted disk for errors with the chkdsk /r command.
To mount an image, perform the following steps.
Source
Archive (p. 238)
Specify the path to the archive location and select the archive containing disk backups.
Backup (p. 239)
Select the backup.
Access credentials (p. 239)
[Optional] Provide credentials for the archive location. To access this option, select the
Advanced view check box.
Mount settings
Volumes (p. 239)
